Airtac GAR Air Regulator GAR20006SJK
The AirTAC Airtac GAR Air Regulator GAR20006SJK is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.9 MPa range, with 1/8" ports and a built-in circular pressure gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.9 MPa
- RegulationStandard
- GaugeCircular
- Reflux valveYes (K)
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006SJK
The GAR20006SJK is an air pressure regulator that takes a higher supply pressure and holds a steady, lower downstream pressure you set with the knob. It is a regulator only - it does not filter, clean, or dry the air, and has no drain bowl or filter element. This unit carries a 1/8in port and weighs 170 g, placing it in the compact GAR200 size class.
Its pressed-in self-locking knob keeps the set pressure from drifting when the machine vibrates or the knob gets knocked. The circular gauge with clip and magnifier is fitted and reads in MPa/psi, saving panel space while staying easy to read. A reverse-flow (reflux) valve is attached to this model.
Airtac GAR Air Regulator GAR20006SJK Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006SJK |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Standard |
| Pressure range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure gauge | Circular, MPa / psi scale |
| Bracket | Not included (J) |
| Reflux valve | Attached (K) |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006SJK
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| S | Standard regulation: 0.05 - 0.9 MPa (7 - 130 psi). This body offers S (standard) or L (lower pressure). |
| J | No bracket (J) — panel mount or existing bracket. |
| (blank) | Circular pressure gauge fitted. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached (K). |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006SJK Is Used
Small Clamp Pressure
Set a steady 0.3 MPa for a small pneumatic clamp on a benchtop fixture. The self-locking knob holds the setting despite the clamp's vibration, keeping holding force consistent.
Single Tool Supply
Regulate pressure for one air tool like a die grinder or blow gun on a workbench. The 1/8in port feeds the tool directly and the gauge lets you confirm the setpoint at a glance.
Lab Air Setpoint
Maintain a precise low pressure for a laboratory air table or small test rig. The balanced design holds the setpoint as the shop supply fluctuates, protecting sensitive equipment.
Is the Airtac GAR Air Regulator GAR20006SJK the Right Regulator?
Choose the GAR200 body when your line uses 1/8in or 1/4in ports and needs a compact 170 g regulator. This model uses the standard type, regulating from 0.05-0.9 MPa (7-130 psi), which suits most shop air systems. The J code means no mounting bracket is included, so plan for panel mounting or an existing bracket. The gauge is fitted and reads MPa/psi per the PT thread standard. The K code adds a reverse-flow (reflux) valve, named here without describing its function. If the line also needs clean air, use a GAFR200 or a separate GAF filter upstream, as this regulator does not filter. The standard type's adjustable band of 0.85 MPa is about 2.4x the lower type's 0.35 MPa span.
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006SJK FAQ
The GAR20006SJK is an air pressure regulator with a 1/8in port and a weight of 170 g. It regulates from 0.05-0.9 MPa (7-130 psi), with a max supply pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -20 to 70 C. It has a fitted circular gauge reading MPa/psi, no mounting bracket, and a reflux valve.
The K code means a reverse-flow (reflux) valve is attached to the GAR20006SJK. This is named as an included feature, but its specific function is not detailed in our data. The regulator itself still only controls pressure and does not filter or clean the air.
