Airtac GAR Air Regulator GAR20006SJN
The AirTAC Airtac GAR Air Regulator GAR20006SJN is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.9 MPa range, with 1/8" ports and a no-gauge (N) port for a panel gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.9 MPa
- RegulationStandard
- GaugeNone (N)
- Reflux valveNo
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006SJN
The GAR20006SJN is a compact air pressure regulator that takes a variable supply and holds a steady downstream pressure you set with its self-locking knob. This 1/8in unit weighs just 170 g, so it suits small panels and tight spaces without needing extra support. It does not filter or clean the air - it only regulates pressure.
This standard-type model regulates from 0.05-0.9 MPa (7-130 psi), with a maximum supply of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). The pressed-in self-locking mechanism keeps your setpoint stable against vibration and accidental knocks. With no gauge fitted, you read the pressure on your line's own panel gauge.
Airtac GAR Air Regulator GAR20006SJN Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006SJN |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Standard |
| Pressure range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure gauge | None (N) — MPa / psi port |
| Bracket | Not included (J) |
| Reflux valve | None |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006SJN
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| S | Standard regulation: 0.05 - 0.9 MPa (7 - 130 psi). This body offers S (standard) or L (lower pressure). |
| J | No bracket (J) — panel mount or existing bracket. |
| N | No gauge (N) — for a line with a panel gauge already. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow (reflux) valve. |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006SJN Is Used
Single clamp control
Set a precise 0.3 MPa for a small pneumatic clamp on a benchtop fixture. The self-locking knob holds the setting even with machine vibration nearby.
Bench tool pressure
Regulate supply to a small air tool like a die grinder or blow gun. The 1/8in port matches light-duty tooling, and the compact 170 g body mounts easily.
Lab air supply
Stabilize a variable shop line down to a consistent 0.2 MPa for a lab fixture or test jig. The balanced design keeps the setpoint steady as supply pressure fluctuates.
Is the Airtac GAR Air Regulator GAR20006SJN the Right Regulator?
Choose the GAR20006SJN when you need a 1/8in regulator for low-flow applications like a single clamp or a small tool. The J code means no mounting bracket is included, so plan for panel mounting or use an existing bracket. The N code means no gauge is fitted - rely on your line's panel gauge instead. This unit uses PT threads with an MPa/psi gauge scale if you add one later. If your air needs cleaning, pair this with a GAF filter upstream or step up to a GAFR200-06 filter-regulator. The S type's adjustable band spans 0.85 MPa, which is about 2.4x the 0.35 MPa band of the L type.
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006SJN FAQ
The GAR20006SJN regulates air from 0.05-0.9 MPa (7-130 psi). Maximum supply pressure is 1.0 MPa (145 psi), proof pressure is 1.5 MPa (215 psi), and operating temperature is -20 to 70 C. The unit weighs 170 g and has a 1/8in port. It has no gauge and no bracket.
The N means no pressure gauge is fitted. You read the downstream pressure on your line's own panel gauge instead. The regulator still functions exactly the same, just without the built-in circular gauge.
