Airtac GAR Air Regulator GAR20006SN
The AirTAC Airtac GAR Air Regulator GAR20006SN is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.9 MPa range, with 1/8" ports and a no-gauge (N) port for a panel gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.9 MPa
- RegulationStandard
- GaugeNone (N)
- Reflux valveNo
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006SN
The AirTAC GAR20006SN is a compact air pressure regulator that takes a higher supply pressure and holds a steady, lower downstream pressure you set with the knob. It is a regulator only - it does not filter the air, remove water, or separate particles, and it has no drain bowl or filter element.
This GAR200 model has a 1/8" port and weighs 170 g, making it the smallest body in the GAR series. The standard (S) type regulates from 0.05-0.9 MPa (7-130 psi). The pressed-in self-locking knob prevents the set pressure from drifting due to vibration or accidental knocks, so your setting stays where you put it.
Airtac GAR Air Regulator GAR20006SN Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006SN |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Standard |
| Pressure range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure gauge | None (N) — MPa / psi port |
| Bracket | Included |
| Reflux valve | None |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006SN
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| S | Standard regulation: 0.05 - 0.9 MPa (7 - 130 psi). This body offers S (standard) or L (lower pressure). |
| (blank) | Mounting bracket included. |
| N | No gauge (N) — for a line with a panel gauge already. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow (reflux) valve. |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006SN Is Used
Small bench tools
Set a stable 0.3 MPa for a small pneumatic screwdriver or a compact bench press where supply pressure fluctuates.
Single clamp circuits
Hold a precise lower pressure for one holding clamp on a fixture, protecting the workpiece from supply swings.
Lab air supply
Regulate a low-pressure air supply for a laboratory test rig that needs a steady, adjustable pressure without filtration.
Is the Airtac GAR Air Regulator GAR20006SN the Right Regulator?
Choose the GAR200 body for small tools or single actuators where a 1/8" port matches the line. The standard S type covers 0.05-0.9 MPa (7-130 psi), which suits most industrial settings; the L type only reaches 0.4 MPa and would be the wrong part for a standard machine. This model has no gauge (N), so read pressure on the line's own panel gauge, and the mounting bracket is included. The PT thread gives a gauge scale in MPa/psi. If the air also needs cleaning, use a GAFR200 or a GAF filter upstream. The S type's adjustable band is about 2.4x the L type's (0.85 MPa vs 0.35 MPa).
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006SN FAQ
The GAR20006SN is an air pressure regulator with a 1/8" port, weighing 170 g. It regulates from 0.05-0.9 MPa (7-130 psi), with a max supply pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). Temperature range is -20 to 70 C. It has no gauge and includes a mounting bracket.
The N means the unit has no pressure gauge fitted. You would read the downstream pressure on the line's own panel gauge or add a separate gauge. This model still regulates pressure normally; the gauge is simply omitted to save cost or panel space.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Related AirTAC Air-Preparation Units
Request a Quote for Airtac GAR Air Regulator GAR20006SN
Send us the quantity, thread type (PT / G / NPT) and destination. We confirm price, stock and lead time — usually within 7-8 hours.
