Airtac GAR Air Regulator GAR20006SNK
The AirTAC Airtac GAR Air Regulator GAR20006SNK is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.9 MPa range, with 1/8" ports and a no-gauge (N) port for a panel gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/8"
- Pressure range0.05 - 0.9 MPa
- RegulationStandard
- GaugeNone (N)
- Reflux valveYes (K)
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20006SNK
The GAR20006SNK is an air pressure regulator that takes a higher supply and holds a steady, lower downstream pressure set by its knob. It does not filter or clean the air, and it has no drain bowl or filter element. This model has a 1/8" port and weighs 170 g, making it the smallest GAR body.
It is the standard type, regulating from 0.05-0.9 MPa (7-130 psi), with a maximum supply of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The pressed-in self-locking knob prevents the set pressure from drifting due to vibration or accidental contact, keeping your downstream process stable. A reverse-flow (reflux) valve is attached to this unit.
Airtac GAR Air Regulator GAR20006SNK Technical Specifications
| Model | Airtac GAR Air Regulator GAR20006SNK |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/8" (PT thread) |
| Regulation type | Standard |
| Pressure range | 0.05 - 0.9 MPa (7 - 130 psi) |
| Pressure gauge | None (N) — MPa / psi port |
| Bracket | Included |
| Reflux valve | Attached (K) |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20006SNK
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| S | Standard regulation: 0.05 - 0.9 MPa (7 - 130 psi). This body offers S (standard) or L (lower pressure). |
| (blank) | Mounting bracket included. |
| N | No gauge (N) — for a line with a panel gauge already. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached (K). |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-06 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/8" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-06 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20006SNK Is Used
Small Clamp Force
Set a precise, repeatable pressure for a small pneumatic clamp on a benchtop fixture. The self-locking knob keeps the force consistent through a shift, and the 1/8" port suits low-flow cylinders.
Single Tool Supply
Regulate pressure for one air tool, such as a small die grinder or blow gun, at a dedicated bench. The 170 g body mounts directly to the panel without stressing the tubing.
Lab Test Rig
Hold a stable test pressure for a leak-check fixture or a calibration setup. The balanced design maintains the setpoint as the plant supply fluctuates, protecting sensitive instruments.
Is the Airtac GAR Air Regulator GAR20006SNK the Right Regulator?
Choose the GAR200 body when your line uses 1/8" or 1/4" ports and needs a compact, lightweight regulator at 170 g. The standard S type covers the full 0.05-0.9 MPa (7-130 psi) band, suitable for most shop air applications; the L type would limit you to 0.05-0.4 MPa (7-58 psi) and cannot reach a 0.5 MPa setpoint. This model has no gauge, so read pressure on your line's own panel gauge, and it includes the mounting bracket. The PT thread reads MPa/psi on any fitted gauge, and the K option means a reflux valve is attached. If your air also needs cleaning, use a GAFR or a separate GAF filter upstream. The S type's adjustable band is about 2.4x the L type's span (0.85 MPa vs 0.35 MPa).
Quick checklist
- ✓ Body size for your air demand (1/8" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-06 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20006SNK FAQ
It is an air pressure regulator with a 1/8" port, weighing 170 g. The standard type regulates from 0.05-0.9 MPa (7-130 psi). Maximum supply pressure is 1.0 MPa (145 psi), and proof pressure is 1.5 MPa (215 psi). Operating temperature is -20 to 70 C. This model has no gauge, includes a mounting bracket, uses PT threads, and has a reflux valve.
The N means no pressure gauge is fitted, so you read the downstream pressure on your line's own panel gauge. The K indicates a reverse-flow (reflux) valve is attached to the regulator. This unit does not filter air; for clean air, use a GAFR or a GAF filter upstream.
