Airtac GAR Air Regulator GAR20008LJ
The AirTAC Airtac GAR Air Regulator GAR20008LJ is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.4 MPa range, with 1/4" ports and a built-in circular pressure gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/4"
- Pressure range0.05 - 0.4 MPa
- RegulationLower pressure
- GaugeCircular
- Reflux valveNo
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20008LJ
The GAR20008LJ is an air pressure regulator that takes a higher supply and holds a steady lower downstream pressure you set with its knob. It does not filter or clean the air, and it has no drain bowl or filter element. This unit carries a circular gauge with a clip and magnifier, so it mounts close to the panel while staying easy to read.
This model uses a 1/4in port on the 170 g GAR200 body, placing it in the smallest size class of the GAR range. It is the lower-pressure L type, regulating from 0.05-0.4 MPa (7-58 psi), which suits low-pressure circuits that need finer adjustment within that band. The pressed-in self-locking knob keeps the setpoint from drifting when the machine vibrates.
Airtac GAR Air Regulator GAR20008LJ Technical Specifications
| Model | Airtac GAR Air Regulator GAR20008LJ |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/4" (PT thread) |
| Regulation type | Lower pressure |
| Pressure range | 0.05 - 0.4 MPa (7 - 58 psi) |
| Pressure gauge | Circular, MPa / psi scale |
| Bracket | Not included (J) |
| Reflux valve | None |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20008LJ
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 08 | Port size 1/4". This body offers 06 = 1/8", 08 = 1/4". |
| L | Lower pressure regulation: 0.05 - 0.4 MPa (7 - 58 psi). This body offers S (standard) or L (lower pressure). |
| J | No bracket (J) — panel mount or existing bracket. |
| (blank) | Circular pressure gauge fitted. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow (reflux) valve. |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-08 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/4" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-08 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20008LJ Is Used
Low-pressure clamping
Set a gentle, repeatable clamp force on a small fixture or work-holder. The L type's finer low-band adjustment lets you dial in a precise pressure without overshooting.
Lab air bench
Feed a sensitive lab instrument or test rig that needs a stable low supply. The balanced design holds the setpoint as the shop supply fluctuates.
Single tool station
Protect a blowgun or a small air tool from supply swings. The self-locking knob keeps your pressure setting steady through a shift of vibration.
Is the Airtac GAR Air Regulator GAR20008LJ the Right Regulator?
Choose the GAR20008LJ when your line needs a compact 1/4in regulator with a low 0.05-0.4 MPa (7-58 psi) range. The L type gives finer resolution over that low band but cannot reach a 0.5-0.6 MPa setpoint, so it is the wrong part for a standard machine. This code omits the mounting bracket (J), so plan for panel mounting or an existing bracket. The gauge is fitted and reads MPa/psi on the PT thread. If the air also needs cleaning, use a GAFR200-08 or a separate GAF filter upstream, since this unit only regulates. The S type's 0.05-0.9 MPa band is about 2.4x the span of this L type's 0.05-0.4 MPa band.
Quick checklist
- ✓ Body size for your air demand (1/4" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-08 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20008LJ FAQ
The GAR20008LJ regulates air from 0.05-0.4 MPa (7-58 psi). Maximum supply pressure is 1.0 MPa (145 psi) and proof pressure is 1.5 MPa (215 psi). It operates from -20 to 70 C and weighs 170 g with a 1/4in port.
The J in the code means the mounting bracket is omitted, so you need a panel mount or an existing bracket. The L type regulates only 0.05-0.4 MPa (7-58 psi), giving finer control over that low band but no ability to reach a standard 0.5-0.6 MPa setpoint.
