Airtac GAR Air Regulator GAR20008LJK
The AirTAC Airtac GAR Air Regulator GAR20008LJK is a genuine compressed-air pressure regulator. It sets and holds a steady downstream pressure across the 0.05 - 0.4 MPa range, with 1/4" ports and a built-in circular pressure gauge. It regulates pressure only — it does not filter the air or remove water.
- TypeAir regulator
- Port size1/4"
- Pressure range0.05 - 0.4 MPa
- RegulationLower pressure
- GaugeCircular
- Reflux valveYes (K)
- Max pressure1.0 MPa
- Weight170 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAR Air Regulator GAR20008LJK
The GAR20008LJK is an air pressure regulator that takes a higher supply and holds a steady lower downstream pressure, set by its knob and read on the fitted circular gauge. It does not filter, clean, or dry the air, and has no drain bowl or filter element.
This lower-pressure (L) model regulates from 0.05 to 0.4 MPa (7-58 psi), with a 1/4in port and a 170 g body. Its pressed-in self-locking knob resists drift from vibration, while the balanced adjustment mechanism keeps the setpoint stable as supply pressure varies.
Airtac GAR Air Regulator GAR20008LJK Technical Specifications
| Model | Airtac GAR Air Regulator GAR20008LJK |
|---|---|
| Series | GAR200 air regulator |
| Port size | 1/4" (PT thread) |
| Regulation type | Lower pressure |
| Pressure range | 0.05 - 0.4 MPa (7 - 58 psi) |
| Pressure gauge | Circular, MPa / psi scale |
| Bracket | Not included (J) |
| Reflux valve | Attached (K) |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -20 to +70 °C |
| Adjustment | Self-locking press-in knob |
| Mounting | Panel + optional bracket |
| Weight | 170 g |
Specifications follow the official AirTAC GAR catalogue (pages 228-229). This is a regulator only — it sets and holds a downstream pressure but does not filter the air or separate water. To clean the air as well, use the matching GAFR200 filter-regulator or add a GAF filter upstream. Never run above the 1.5 MPa (215 psi) proof pressure.
Model Code: Airtac GAR Air Regulator GAR20008LJK
| GAR200 | GA200 series air regulator — sets the port range and weight class. |
|---|---|
| 08 | Port size 1/4". This body offers 06 = 1/8", 08 = 1/4". |
| L | Lower pressure regulation: 0.05 - 0.4 MPa (7 - 58 psi). This body offers S (standard) or L (lower pressure). |
| J | No bracket (J) — panel mount or existing bracket. |
| (blank) | Circular pressure gauge fitted. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached (K). |
A GAR regulates pressure but does not filter — there is no bowl, element or drain code. Need to clean the air too? The matching GAFR200-08 is the same regulator with a built-in filter.
Size Class
- GAR2001/8"-1/4" · 170 g
- GAR3001/4"-1/2" · 300 g
- GAR4003/8"-1/2" · 570 g
- GAR5003/4" · 580 g
- GAR6003/4"-1" · 1390 g
All bodies share the same 0.05-0.9 MPa (S) regulated range, 1.0 MPa max and 1.5 MPa proof; the body number sets the port size and the flow the regulator can pass. Bigger ports feed higher air demand. The catalogue plots a flow curve at 0.7 MPa inlet but prints no numeric envelope, so size by port and weight and confirm the curve for a real duty point.
| This model | GAR200 · 1/4" · 170 g |
|---|---|
| One size up | GAR300 |
| Add filtration | GAFR200-08 (filter + regulator) |
Where the Airtac GAR Air Regulator GAR20008LJK Is Used
Low-pressure clamping
Set a gentle, repeatable 0.1 MPa for a delicate workpiece clamp on a small bench fixture, where the L type's finer low-band resolution prevents over-force.
Lab air supply
Feed a 1/4in line to a laboratory pneumatic actuator that needs a stable 0.2 MPa, isolated from supply swings in the plant air system.
Paint spray gun feed
Hold a steady low pressure for a touch-up spray gun, using the fitted gauge to verify the setpoint and the self-locking knob to keep it fixed.
Is the Airtac GAR Air Regulator GAR20008LJK the Right Regulator?
Choose the body and port to match your line size: this GAR200 uses a 1/4in port and is the lightest body at 170 g, while the GAR300 (300 g) offers 1/4in to 1/2in ports for higher flow demand. The L type regulates only 0.05-0.4 MPa (7-58 psi), so it suits low-pressure tasks but cannot reach a 0.5-0.6 MPa setpoint; pick the S type for standard 0.05-0.9 MPa work. The circular gauge is fitted and reads MPa/psi on the PT thread, the J code omits the mounting bracket for panel mounting, and the K code attaches a reverse-flow (reflux) valve. If the line also needs clean air, use a GAFR filter-regulator or a GAF filter upstream. The S type's 0.05-0.9 MPa band is about 2.4x wider than this L type's 0.05-0.4 MPa span.
Quick checklist
- ✓ Body size for your air demand (1/4" here)
- ✓ Type S (0.05-0.9) or L (0.05-0.4 MPa)
- ✓ Gauge fitted, or no gauge (N)
- ✓ Thread PT / G / NPT (sets gauge scale)
- ✓ Bracket kept or removed (J)
- ✓ Need filtration too? Use GAFR200
Installation & Setting Notes
- check Install with the airflow arrow: IN to OUT, knob accessible.
- check Put a filter (GAF or a GAFR) UPSTREAM — a regulator does not clean the air.
- check Set pressure by turning the knob up to the target, then press it in to lock.
- check Keep supply at or below the 1.0 MPa (145 psi) max working pressure.
- check Never exceed the 1.5 MPa (215 psi) proof pressure.
- check Support the 170 g unit on its panel or bracket, not on the tubing.
This is a regulator only — it sets and holds pressure but does not filter or lubricate. Add a GAF filter, a GAL lubricator, or step up to the GAFR200-08 filter-regulator as your air-prep needs grow.
Airtac GAR Air Regulator GAR20008LJK FAQ
The GAR20008LJK is a lower-pressure regulator with a 1/4in port, regulating from 0.05 to 0.4 MPa (7-58 psi). Maximum supply pressure is 1.0 MPa (145 psi), proof pressure is 1.5 MPa (215 psi), temperature range is -20 to 70 C, and it weighs 170 g. It has a fitted circular gauge, no bracket, and a reflux valve.
The L type regulates only 0.05-0.4 MPa (7-58 psi), giving finer resolution over that low band compared to the standard S type, but it cannot reach higher setpoints. The K code means a reverse-flow (reflux) valve is attached to the unit.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Related AirTAC Air-Preparation Units
Request a Quote for Airtac GAR Air Regulator GAR20008LJK
Send us the quantity, thread type (PT / G / NPT) and destination. We confirm price, stock and lead time — usually within 7-8 hours.
