Airtac JSID Double Rod Cylinder JSID100X200S
The AirTAC Airtac JSID Double Rod Cylinder JSID100X200S is a genuine double acting, double rod JIS-standard air cylinder with a Ø100mm bore and 200mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke200 mm
- Port sizeG1/2
- Acting typeDouble acting, double rod
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSID Double Rod Cylinder JSID100X200S
Delivering 3574 N of thrust in both directions at 0.5 MPa, this 100 mm bore double-rod actuator uses a single piston with a rod exiting each cover to ensure perfectly symmetric output. The G1/2 ported hard-anodized aluminum profile barrel keeps the total build shorter than a same-bore ISO 15552 unit. This equal-both-ways force translates to a safe working load of about 2144 N, or roughly 182 kg lifted vertically with a 2:1 margin.
The JSID100X200S variant includes a built-in piston magnet for CMSE/DMSE switches that drop directly into the side grooves. Adjustable 33 mm air cushions at both ends absorb kinetic energy near stroke end, though a plain cylinder drifts on air loss, so fit an external rod lock or pilot-operated check valve if you need to hold a suspended load.
Airtac JSID Double Rod Cylinder JSID100X200S Technical Specifications
| Model | Airtac JSID Double Rod Cylinder JSID100X200S |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 200 mm |
| Acting type | Double acting, double rod |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) | — |
|---|---|---|
| 0.5 MPa | 3525 N | 3525 N |
| 0.7 MPa | 4935 N | 4935 N |
| Max (@1.0 MPa) | 801 kgf | |
Double-rod: the rod passes through both covers, so output force is equal in both directions.
Model Code: Airtac JSID Double Rod Cylinder JSID100X200S
| JSID | JIS-standard profile cylinder (double-rod type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSID Double Rod Cylinder JSID100X200S Is Used
Twin-Spindle Machining
Drives two opposing machining heads simultaneously from a single symmetric piston, keeping cutting forces balanced.
Dual-End Transfer Pusher
Uses the extending rear rod to index a secondary conveyor lane while the front rod pushes the primary workpiece.
Anti-Rotation Lift Gate
Lifts heavy vertical gates without twisting, using the rigid double-rod geometry to maintain parallel alignment.
Is the Airtac JSID Double Rod Cylinder JSID100X200S the Right Cylinder?
This 100 mm bore sits near the top of the range, stepping down from the 125 mm option (5734 N at 0.5 MPa) and up from the 80 mm size (2268 N at 0.5 MPa). Choose a double-rod configuration when your machine needs anti-rotation stability, twin tooling driven from both ends, a symmetric load path, or a rear cam for end-of-stroke sensing. The JSID mounting set covers Basic, FA, LB, TC, TCM1, and TCM2. Because this is the -S magnet version, it is ready for CMSE/DMSE sensors. For this 200 mm stroke, ensure external guide rails carry the side-load to prevent binding.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSID Double Rod Cylinder JSID100X200S FAQ
Because the rod passes through both covers, force is equal in both directions using the pull-side area. It generates 3574 N at 0.5 MPa and 5003 N at 0.7 MPa each way, with a theoretical max of 729 kgf at 1.0 MPa. It features a G1/2 port, a 32 mm rod, M26x1.5 rod thread, and adjustable 33 mm cushions.
The -S suffix means a magnet is installed for CMSE/DMSE reed or electronic switches that fit into the barrel grooves. Note that the air cushions only decelerate the piston near stroke end; the cylinder will drift on air loss, so you must use an external rod lock or pilot-operated check valve for load holding.
