Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S
The AirTAC Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S is a genuine double-acting aluminum-barrel mini cylinder with a Ø20mm bore, a 100mm nominal stroke and a rear adjustable-stroke stopper — trim up to 100mm for a usable window of 0–100mm. Adjustable air cushion (both ends).
- BoreØ20 mm
- Stroke100 mm
- Adjustable0–100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionAdjustable air cushion (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S
The AirTAC MBLCJ20X100-100S is a compact double-acting mini cylinder featuring a 20mm bore and a 100mm stroke. A rear adjuster allows trimming up to 100mm of travel, yielding a usable 0-100mm end-position window. It generates 157N of push force at 0.5MPa and integrates an adjustable air cushion at both ends to tune deceleration. The -S code denotes a built-in magnet for CMSG, DMSG, or EMSG sensor switches.
Distinguish the rear travel stopper from the cushion: the stopper sets the end position, while the cushion screws regulate end-of-stroke speed to protect the end covers. The riveted aluminum barrel and 20um hard-chrome plated Ø8 carbon-steel rod withstand rapid 30-800mm/s cycles. Note the overall length equals A plus 200mm plus the 100mm adjuster, requiring careful spatial planning in tight assemblies.
Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S Technical Specifications
| Model | Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S |
|---|---|
| Series | MBL aluminum-barrel mini round cylinder (adjustable stroke) |
| Bore size | Ø20 mm |
| Nominal stroke | 100 mm |
| Adjustable window | 0–100 mm (trim 100 mm) |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable air cushion (both ends) |
| Max standard stroke | Up to 300 mm |
The rear stopper sets the end position — it is a travel stop, not a lock. Overall length = A + 2 × stroke + adjustable stroke. MBLJ/MBLCJ mounting is Basic / FA / LB only (no SDB, no back-cover code). Thread options: PT / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | — |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a margin.
Model Code: Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S
| MBLCJ | MBLCJ aluminum-barrel adjustable-stroke mini cylinder with adjustable cushion. |
|---|---|
| 20 | Bore size in mm. |
| ×100 | Nominal stroke length in mm. |
| -100 | Adjustable-stroke amount (mm you can trim at the rear). |
| S | Optional built-in magnet for a CMSG/DMSG/EMSG sensor switch. |
Related: MBLJ (adjustable stroke, fixed bumper), MBL (fixed stroke), MBLD (double rod).
Where the Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S Is Used
PCB Pick & Place
Uses the 0-100mm adjustable window to precisely set component insertion depth on a pick-and-place head, relying on the 157N force and air cushion for soft landing.
Dispenser Valve Cutoff
Tunes the exact retract distance for an adhesive dispenser nozzle, while the cushion valve halts the 100mm stroke smoothly to prevent fluid tailing.
Small Parts Ejector
Pushes stamped micro-parts from a die set; the DMSG electronic sensor tracks the 8mm rod position for high-speed ejection timing.
Is the Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S the Right Cylinder?
At 157N push (0.5MPa), this 20mm bore suits light loads; step down if moving just a micro-actuator, or step up to the 25mm bore (245N push) for heavier resistance. Choose this MBLCJ over the MBLJ when movable end-covers are needed to absorb kinetic energy instead of relying on a fixed rubber bumper. The rear stopper and cushion valve decelerate the load but do not lock position—rod drift occurs without live air, so use an external locking mechanism for true holding. Mounting is limited to Basic, FA, or LB (no SDB or back-cover), and the G1/8 port uses a default PT thread form.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Adjustable window fits your end position
- ✓ Adjuster is a travel stop, not a lock
- ✓ Magnet (S) for sensors?
- ✓ Side load — add a guide on long strokes
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Set the rear stopper for the end position (a travel stop, not a lock).
- check Avoid side load; add an external guide on long strokes.
- check Mounting: Basic / FA flange / LB foot (no SDB, no back-cover code).
- check Installation by qualified personnel per AirTAC docs.
Airtac MBLCJ Adjustable Mini Cylinder MBLCJ20X100-100S FAQ
At 0.5MPa, the 20mm bore provides 157N push and 132N pull. At 0.7MPa, push increases to 220N. The maximum theoretical force is 32kgf at 1.0MPa.
The 100mm rear adjuster acts as a travel stop to set your exact 0-100mm end position, while the adjustable air cushion uses screw valves to regulate deceleration speed near the covers. Neither holds the load without air pressure.
