Airtac MFD Double Rod Miniature Cylinder MFD20X250S
The AirTAC Airtac MFD Double Rod Miniature Cylinder MFD20X250S is a genuine double acting, double rod JIS-standard round-body mini air cylinder with a Ø20mm bore and 250mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel for mildly corrosive environments. For the same bore and stroke it is shorter than an ISO 6432 cylinder, saving mounting space.
- BoreØ20 mm
- Stroke250 mm
- Port size1/8"
- Acting typeDouble acting, double rod
- Rod threadM8×1.25
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MFD Double Rod Miniature Cylinder MFD20X250S
With a rod exiting both covers, the MFD20X250S delivers 131.9 N at 0.5 MPa in each direction, making it a balanced actuator for guided slides and twin-tool setups. The twin rods resist rotation and reduce side-play, giving steadier motion than a single-rod mini cylinder of the same bore.
This JIS-standard round-body cylinder uses a SUS304 stainless barrel with riveted aluminium covers, so it is shorter than an ISO 6432 cylinder for the same bore and stroke. The built-in magnet (-S) accepts CMSG, DMSG, or EMSG switches for position sensing. Air ports are 1/8" PT (G or NPT optional).
Airtac MFD Double Rod Miniature Cylinder MFD20X250S Technical Specifications
| Model | Airtac MFD Double Rod Miniature Cylinder MFD20X250S |
|---|---|
| Series | MFD JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 250 mm |
| Acting type | Double acting, double rod |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MF/MFC (JIS-standard) datasheet. Barrel: SUS304 stainless steel; covers: aluminum alloy (round-body, riveted rolling-packed construction). Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 132 N |
| 0.7 MPa | 185 N |
| Max (@1.0 MPa) | 27 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac MFD Double Rod Miniature Cylinder MFD20X250S
| MFD | JIS-standard round-body mini cylinder (double-rod). |
|---|---|
| 20 | Bore size in mm. |
| ×250 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MF-family variants: MF / MFC (double acting ±cushion), MSF / MTF (single acting push / pull), MFD / MFCD (double rod ±cushion), MFJ / MFCJ (adjustable stroke ±cushion). Back covers CA / U / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MFD Double Rod Miniature Cylinder MFD20X250S Is Used
Anti-Rotation Slide
Guides a 131.9 N load on a linear slide where the twin rods prevent rotational drift, keeping the tool orientation stable across the full 250 mm stroke.
Twin-Tool Actuation
Drives two small grippers or probes simultaneously-one on each rod end-using the equal 131.9 N force at 0.5 MPa for synchronized pick-and-place tasks.
Back-Rod Switching
Mounts a CMSG sensor on the rear rod to trigger a downstream conveyor or valve at a precise mid-stroke position, using the -S magnet for reliable detection.
Is the Airtac MFD Double Rod Miniature Cylinder MFD20X250S the Right Cylinder?
Choose between MFD20 and MFD25 based on your force needs: the MFD20 delivers 131.9 N at 0.5 MPa, while the MFD25 provides 206.1 N at the same pressure. For a 250 mm stroke with anti-rotation requirements, the double-rod design of the MFD20X250S handles about 6.7 kg vertically with a 2:1 safety margin. Note that this cylinder does not hold position on air loss; use an external rod lock or pilot check valve for load holding. Select LB foot, FA flange, or TC trunnion mounting, and remember the -S magnet enables sensor attachment.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MFD Double Rod Miniature Cylinder MFD20X250S FAQ
Because it is double-rod, force is equal both ways: 131.9 N at 0.5 MPa, 184.7 N at 0.7 MPa, with a theoretical maximum of 26.9 kgf at 1.0 MPa. The rod-side area determines output, so there is no larger push direction.
The second rod exits the back cover, giving you equal force in both directions and inherent anti-rotation. It also provides a mounting point for sensors or a second tool. The -S magnet enables CMSG, DMSG, or EMSG switches for position feedback.
