Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S
The AirTAC Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S is a double-acting pen-size mini cylinder with a rear adjuster screw that shortens the retract end of the stroke. On a Ø10mm bore it gives a nominal 10mm stroke with a 10mm fine-adjustable window, so you set the end position without changing hardware.
- BoreØ10 mm
- Nominal stroke10 mm
- Adjust window10 mm
- Effective range0–10 mm
- Port sizeM5×0.8
- Acting typeDouble acting
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S
The AirTAC PBJ10X10-10S is a double-acting, single-rod pen-size mini cylinder with a 10mm bore and a 10mm adjustable-stroke window. A rear adjuster screw shortens the retract end, providing an effective stroke range of 0 to 10mm. Output force equals a standard PB body, delivering about 39.3 N push at 0.5 MPa. The extend end remains fixed, so only the back position changes. The integrated magnet works with reed or electronic switches.
Built with a SUS304 stainless rod and barrel, this slim unit saves space in tight jigs. It features a fixed TPU bumper at each end to decelerate motion near the stroke limits. The M5x0.8 air port and M8x1.0 rod-end thread match the standard 10mm bore configuration. Remember to re-tighten the lock nut after setting the rear screw, as vibration can drift an unlocked adjuster.
Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S Technical Specifications
| Model | Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S |
|---|---|
| Series | PBJ JIS pen-size adjustable-stroke cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Nominal stroke | 10 mm |
| Adjustable window | 10 mm (0–10 mm) |
| Adjuster thread | M4×0.7 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 100 mm |
The adjuster shortens only the retract end; the extend end is fixed. Force is unchanged from the standard PB double-acting cylinder. Confirm the set position against the product label before installation.
Theoretical Output Force (Ø10mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 39.3 N | 33.0 N |
| 0.7 MPa (max) | 55.0 N | 46.2 N |
Adjusting the stroke does not change output force — these are the same values as the standard PB double-acting cylinder of the same bore. Size with a friction margin.
Model Code: Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S
| PBJ | JIS pen-size adjustable-stroke mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×10 | Nominal stroke length in mm. |
| -10 | Adjustable-stroke window in mm (10/20/30/40/50/75/100). |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (fixed stroke), PBD (double rod), PBR (front-mount).
Where the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S Is Used
Changeover Fixtures
Set exact retract positions during product changeovers without machining new hard stops.
Trial Stops
Dial in the 0-10mm range to find the perfect end position during prototype testing.
Variable Depth Insertion
Control precise downward insertion depths for delicate pins or light plugs.
Is the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S the Right Cylinder?
When sizing this 10mm bore model, consider the next bore up (12mm) for 56.5 N push at 0.5 MPa if more power is needed, as the 10mm bore is the smallest available. Plan for a safe working load of about 24 N, which is roughly 60% of the 39.3 N theoretical force at 0.5 MPa. For vertical lifts, expect to raise about 2 kg with a 2:1 safety margin. The thin Ø4 mm piston rod is built for coaxial thrust, so add an external guide if side loads are present. Confirm your bore, stroke, window, S magnet, and mounting choice before ordering.
Quick checklist
- ✓ Need to fine-tune the end position on site
- ✓ Retract end sits within 0–10 mm
- ✓ Force at your working pressure
- ✓ Magnet (S) for sensors?
- ✓ Access to the rear adjuster screw
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Set the adjuster, then re-lock the check nut.
- check The adjuster shortens the retract end only.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X10-10S FAQ
The effective stroke range is 0 to 10mm. Force is unchanged from a standard PB cylinder: 39.3 N push and 33 N pull at 0.5 MPa, or 55 N push and 46.2 N pull at the 0.7 MPa maximum.
The rear M4x0.7 screw shortens only the retract end, while the extend end remains fixed. You must re-tighten the lock nut after setting your desired position to prevent vibration drift.
