Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S
The AirTAC Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S is a double-acting pen-size mini cylinder with a rear adjuster screw that shortens the retract end of the stroke. On a Ø10mm bore it gives a nominal 100mm stroke with a 20mm fine-adjustable window — settable from 80 to 100mm, so you set the end position without changing hardware.
- BoreØ10 mm
- Nominal stroke100 mm
- Adjust window20 mm
- Effective range80–100 mm
- Port sizeM5×0.8
- Acting typeDouble acting
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S
The AirTAC PBJ10X100-20S is a double-acting, single-rod pen-size mini cylinder with a 10 mm bore and a 100 mm nominal stroke. A rear adjuster screw (M4x0.7 thread) shortens the retract end, giving an effective stroke range of 80-100 mm. You set the exact back position on the machine without buying new hardware. The extend end remains fixed. Output force matches a standard PB cylinder of the same bore, delivering 39.3 N push at 0.5 MPa.
Built with a SUS304 stainless steel rod and barrel, this slim cylinder saves space in tight jigs and light end-of-arm tooling. It features a fixed TPU bumper at each end and a built-in piston magnet (-S) for position sensing. The M5x0.8 port matches the 10 mm bore size. For smooth operation, plan for a safe working load of about 24 N, which is roughly 60% of the 0.5 MPa push rating, accounting for seal friction.
Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S Technical Specifications
| Model | Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S |
|---|---|
| Series | PBJ JIS pen-size adjustable-stroke cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Nominal stroke | 100 mm |
| Adjustable window | 20 mm (80–100 mm) |
| Adjuster thread | M4×0.7 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 100 mm |
The adjuster shortens only the retract end; the extend end is fixed. Force is unchanged from the standard PB double-acting cylinder. Confirm the set position against the product label before installation.
Theoretical Output Force (Ø10mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 39.3 N | 33.0 N |
| 0.7 MPa (max) | 55.0 N | 46.2 N |
Adjusting the stroke does not change output force — these are the same values as the standard PB double-acting cylinder of the same bore. Size with a friction margin.
Model Code: Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S
| PBJ | JIS pen-size adjustable-stroke mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×100 | Nominal stroke length in mm. |
| -20 | Adjustable-stroke window in mm (10/20/30/40/50/75/100). |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (fixed stroke), PBD (double rod), PBR (front-mount).
Where the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S Is Used
Changeover Fixtures
Dial in the 80-100 mm retract position during product changeovers. The rear screw lets operators set new stops rapidly without machining replacement spacers.
Trial Stops
Set precise end-of-stroke limits for prototype tooling. You can tune the retract distance in 1 mm increments and lock the nut once the optimal position is found.
Variable Insertion
Control insertion depth on light assembly lines. The 39.3 N push force at 0.5 MPa handles delicate tasks while the adjuster allows quick depth changes.
Is the Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S the Right Cylinder?
This 10 mm bore provides 39.3 N push at 0.5 MPa. If you need less force, the smaller bore options offer lower thrust; if your fixture requires more power, stepping up to a 12 mm bore yields 56.5 N push. Remember that adjusting the stroke only affects the retract end—the extend position is fixed. After dialing in your 80-100 mm range, re-tighten the lock nut so vibration does not drift the M4x0.7 screw.
Confirm your ordering essentials: 10 mm bore, 100 mm nominal stroke, 20 mm adjuster window, S magnet, and any LB or FA mounting hardware. The Ø4 mm piston rod is built for coaxial thrust; over this 100 mm stroke or with off-axis loads, add an external guide or linear bearing to prevent side-load damage.
Quick checklist
- ✓ Need to fine-tune the end position on site
- ✓ Retract end sits within 80–100 mm
- ✓ Force at your working pressure
- ✓ Magnet (S) for sensors?
- ✓ Access to the rear adjuster screw
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Set the adjuster, then re-lock the check nut.
- check The adjuster shortens the retract end only.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PBJ Adjustable Pen-Type Cylinder PBJ10X100-20S FAQ
The effective stroke range is 80-100 mm (nominal 100 mm minus the 20 mm adjuster window). Force is identical to a standard PB 10 mm cylinder: 39.3 N push and 33 N pull at 0.5 MPa; 55 N push and 46.2 N pull at the 0.7 MPa maximum.
The rear M4x0.7 screw shortens only the retract end; the extend end is fixed. You must re-tighten the lock nut after setting to prevent vibration drift. The built-in magnet (-S) works with AirTAC reed or electronic switches for position sensing.
