Airtac PSB Single Acting Compact Cylinder PSB6X35SR
The AirTAC Airtac PSB Single Acting Compact Cylinder PSB6X35SR is a single acting, push type (spring return) pen-size mini cylinder with a Ø6mm bore and 35mm stroke. A single air port drives the push stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ6 mm
- Stroke35 mm
- Port sizeM5×0.8
- Acting typePush, single acting
- Rod threadM5×0.8
- ReturnSpring
About the Airtac PSB Single Acting Compact Cylinder PSB6X35SR
The AirTAC PSB6X35SR is a JIS pen-size single-acting push cylinder that extends via one M5x0.8 air port and retracts via a built-in spring. It provides 10.6 N of net push at 0.5 MPa, with a slim SUS304 stainless body suited for tight jigs. Because the spring constantly opposes the air stroke, the rod remains safely retracted if air pressure drops.
This model includes a built-in piston magnet for position sensing and an axial R back cover for in-line plumbing. A fixed TPU bumper cushions the stroke ends. For reliable operation, plan for a safe working load of roughly 6 N, which accounts for seal friction at 60 percent of the rated force.
Airtac PSB Single Acting Compact Cylinder PSB6X35SR Technical Specifications
| Model | Airtac PSB Single Acting Compact Cylinder PSB6X35SR |
|---|---|
| Series | PSB JIS pen-size mini cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 35 mm |
| Acting type | Single acting, push type (spring return) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are the usable push forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSB Single Acting Compact Cylinder PSB6X35SR
| PSB | JIS pen-size single acting, push type (spring return) mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×35 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R / U / CB | Back cover: R axial inlet, U 90° side inlet, CB double clevis (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PTB (single-acting pull), PBD (double rod), PBR (front-mount).
Where the Airtac PSB Single Acting Compact Cylinder PSB6X35SR Is Used
Small Part Ejector
Pushes lightweight plastic components out of a machining fixture, with the spring safely pulling the rod back when air is cut.
Package Diverter Gate
Acts as a compact routing flap on a packaging line, using the single air line to extend and block flow momentarily.
Lab Sample Marker
Depresses a stamping head onto test tubes in a damp environment, relying on the stainless build and fail-safe retract.
Is the Airtac PSB Single Acting Compact Cylinder PSB6X35SR the Right Cylinder?
This 6 mm bore generates 10.6 N net push at 0.5 MPa, sitting between the smaller 4 mm bore (4.1 N) and the larger 10 mm bore (29.8 N). The internal return spring demands a minimum operating pressure of 0.2 MPa before the rod begins moving. When ordering, verify the 35 mm stroke, the S magnet option, the R axial inlet, and your required mounting bracket.
The slender Ø3 mm piston rod handles coaxial thrust well but requires an external linear bearing if subjected to off-axis loads over this 35 mm stroke. With a 2:1 safety margin, expect to lift about 0.5 kg vertically.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PSB Single Acting Compact Cylinder PSB6X35SR FAQ
It delivers 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa maximum. Because an internal spring returns the rod, a minimum pressure of 0.2 MPa is required to overcome the spring before extension begins.
It uses a fixed TPU bumper at each end to decelerate the last few millimeters of travel; at higher speeds with real tooling mass, meter-out the exhaust or add an external shock absorber. The S suffix denotes a built-in magnet compatible with reed or electronic switches.
