Airtac PSB Single Acting Compact Cylinder PSB6X45R
The AirTAC Airtac PSB Single Acting Compact Cylinder PSB6X45R is a single acting, push type (spring return) pen-size mini cylinder with a Ø6mm bore and 45mm stroke. A single air port drives the push stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ6 mm
- Stroke45 mm
- Port sizeM5×0.8
- Acting typePush, single acting
- Rod threadM5×0.8
- ReturnSpring
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PSB Single Acting Compact Cylinder PSB6X45R
The AirTAC PSB6X45R is a JIS pen-size single-acting push cylinder with a 45 mm stroke. Air entering the single M5x0.8 axial port extends the Ø3 mm rod, while an internal spring retracts it upon exhaust. This fail-safe design ensures the rod returns home if air pressure drops, making it ideal for part ejection and clamping tasks. It yields 10.6 N of net push at 0.5 MPa.
Built with a SUS304 stainless barrel and rod, the slim mini body fits tight jigs and light end-of-arm tooling. A fixed TPU bumper cushions the stroke ends. Because the return spring opposes motion, plan for a safe working load of roughly 6 N (about 60 percent of the rated force) to account for seal friction and smooth travel.
Airtac PSB Single Acting Compact Cylinder PSB6X45R Technical Specifications
| Model | Airtac PSB Single Acting Compact Cylinder PSB6X45R |
|---|---|
| Series | PSB JIS pen-size mini cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 45 mm |
| Acting type | Single acting, push type (spring return) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are the usable push forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSB Single Acting Compact Cylinder PSB6X45R
| PSB | JIS pen-size single acting, push type (spring return) mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R / U / CB | Back cover: R axial inlet, U 90° side inlet, CB double clevis (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PTB (single-acting pull), PBD (double rod), PBR (front-mount).
Where the Airtac PSB Single Acting Compact Cylinder PSB6X45R Is Used
Small Part Ejector
Pushes lightweight stamped components off a conveyor lane. The spring-return design guarantees the ejector clears the belt path if the air supply fails.
Clamp Release Mechanism
Applies a steady 6 N holding force against a machined fixture. Releasing air pressure automatically retracts the rod to free the part for unloading.
Carton Flap Folder
Extends to tuck minor flaps on small boxes before sealing. The compact pen-size body mounts easily between adjacent packaging rails.
Is the Airtac PSB Single Acting Compact Cylinder PSB6X45R the Right Cylinder?
This 6 mm bore provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. If your task needs less force, the 4 mm bore offers 4.1 N at 0.5 MPa; for heavier pushing, step up to the 10 mm bore at 29.8 N. The internal spring requires a minimum 0.2 MPa operating pressure before the rod begins moving. For vertical lifts, expect to raise about 0.5 kg safely with a 2:1 margin.
When ordering, confirm the 6 mm bore, 45 mm stroke, lack of a magnetic sensor, and the R axial back cover. The slender Ø3 mm rod handles coaxial thrust well, but over this 45 mm stroke or under off-axis loads, add an external linear bearing to prevent side-loading damage.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PSB Single Acting Compact Cylinder PSB6X45R FAQ
It delivers 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa maximum. The return spring sets a 0.2 MPa minimum pressure before the rod moves, and the cylinder fails safe to the retracted position on air loss.
It uses a fixed TPU bumper at each end to decelerate the stroke. This bumper is not adjustable; at higher speeds with real tooling mass, meter-out the exhaust or add an external shock absorber to prevent bottoming out.
