Airtac PSL Throttle Speed Control Fitting PSL1002B
The AirTAC Airtac PSL Throttle Speed Control Fitting PSL1002B is a genuine speed controller, threaded elbow with knob with aluminium-alloy locking cap and fixed tube direction, used to set the speed of a pneumatic cylinder by throttling its air.
- TypeSpeed controller, threaded elbow
- SeriesPSL
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- AdjustmentKnob with aluminium-alloy locking cap
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PSL Throttle Speed Control Fitting PSL1002B
The PSL1002B is an inline speed controller that screws into a 1/4in PT port and takes Dia 10mm soft nylon or polyurethane tubing on the outlet. Its brass throttling column slows the air in one direction only, so the actuator speed is set where you need it while the opposite flow path stays wide open. The B suffix marks it as a meter-in type: flow from the thread port to the tube runs free, and the reverse path from tube back to thread is throttled. The handle is stamped B so nobody on the shop floor has to guess.
Meter-in control suits single-acting cylinders, where air is supplied against the spring on the extend stroke and throttling that supply is what sets the speed. AirTAC's own catalogue puts meter-out first for double-acting cylinders, because meter-in on a loaded double-acting cylinder tends to stick-slip. Adjustment is by an aluminium-alloy knob with a locking cap: set the speed, then tighten the cap so vibration cannot drift it. Body construction combines a brass throttling column with a PBT plastic holder and NBR seals, in the standard grey finish.
Airtac PSL Throttle Speed Control Fitting PSL1002B Technical Specifications
| Model | Airtac PSL Throttle Speed Control Fitting PSL1002B |
|---|---|
| Type | Speed controller, threaded elbow |
| Series | PSL |
| Adjustment | Knob with aluminium-alloy locking cap |
| Orientation | Fixed tube direction |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. A speed controller is not a shut-off valve - a small leak past a fully closed needle is normal. Close it before applying air, and turn it open slowly. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PSL Throttle Speed Control Fitting PSL1002B
| PSL | Speed controller, threaded elbow. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| A / B | A = meter-out (controls flow from the thread port to the tube). B = meter-in. |
| D | Black. Blank = grey. |
Meter-Out or Meter-In?
- check Meter-out (A) is the default. It throttles the air LEAVING the cylinder, so the piston runs against a back-pressure cushion and moves smoothly.
- check Use meter-out on double-acting cylinders - it is the one AirTAC lists as first priority.
- check Meter-in (B) throttles air ENTERING the cylinder. It suits single-acting cylinders and air motors.
- check Meter-in on a double-acting cylinder tends to give a jerky, stick-slip stroke under varying load.
- check Fit the controller at the cylinder port, not at the valve, so the throttled volume is as small as possible.
Where the Airtac PSL Throttle Speed Control Fitting PSL1002B Is Used
Spring-return clamp on a press fixture
A single-acting clamp cylinder lowering onto a finished anodised surface can be fed through the free meter-in path and slowed by throttling its spring return, so the clamp settles instead of striking the part.
Glue-bead dispensing arm
On a packaging line where a single-acting tip applicator must track a carton seam at a fixed pace, meter-in control on the Dia 10mm supply line keeps the stroke speed steady as the nozzle tracks.
Tail-lift locking pin
A spring-applied locking pin on a truck tail-lift benefits from a damped release stroke; throttling the return path keeps the pin from slamming out of its detent under road vibration.
Is the Airtac PSL Throttle Speed Control Fitting PSL1002B the Right Part?
Confirm the control direction before ordering. Meter-in (B) is right for a single-acting cylinder driven by a solenoid valve; if you are slowing the exhaust of a double-acting cylinder, you want the A version, PSL1002A, instead. On size: the neighbour below on the same 1/4in thread is PSL802B with a Dia 8mm bore, a step down in tubing that trims the volume being controlled; Dia 12mm does not exist on a 1/4in thread in the PSL ladder, so the step up is PSL1203B, which moves to a 3/8in thread and a Dia 12mm bore. If you want the tube to swivel after installation rather than point one fixed way, the PSS802B or PSS1203B universal versions are the equivalents.
Fit the controller directly at the cylinder port, not back at the valve manifold. The throttle only works on the air between the restriction and the actuator, so keeping that volume small makes the speed setting far more predictable and repeatable.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
- ✓ Meter-out (A) unless you know you need meter-in
Airtac PSL Throttle Speed Control Fitting PSL1002B FAQ
This PSL1002B is a Dia 10mm tube by 1/4in PT thread, meter-in (B) speed controller. Working pressure is 0 to 1.0 MPa (0 to 10 kgf/cm2), proof pressure is 1.5 MPa, and it holds vacuum down to -750 mmHg (10 Torr). The usable temperature range is -20 to +70 C. It runs on soft nylon or polyurethane tubing in the standard grey finish.
The B marking means meter-in: the free flow is from the 1/4in thread port to the tube, and the throttled direction is the return. AirTAC designs the B type for single-acting cylinders, where throttling the supply sets the stroke. On a double-acting cylinder, meter-in commonly causes stick-slip under varying load, so fit the meter-out PSL1002A instead and throttle the exhaust for a smooth, cushioned stroke.
