Airtac SAID100 Double Rod Cylinder SAID100AX300S
The AirTAC Airtac SAID100 Double Rod Cylinder SAID100AX300S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø100mm bore and 300mm stroke, G1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ100 mm
- Stroke300 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID100 Double Rod Cylinder SAID100AX300S
The AirTAC SAID100X300-S is a double-acting, double-rod profile cylinder fully dimensionally interchangeable per ISO 15552. Because a rod exits both ends, the annulus area is identical on extend and retract, yielding an equal 3681 N of force each way at 0.5 MPa. This symmetric thrust is ideal for mechanisms requiring perfectly balanced push and pull dynamics.
This specific configuration features a SUS420J2 stainless steel rod (option A) for superior corrosion resistance and includes a magnet for position sensing. You can mount the primary workpiece on the front rod end and a cam or position flag on the rear, while dual-side sensor grooves accept AirTAC CMSE reed or DMSE solid-state switches.
Airtac SAID100 Double Rod Cylinder SAID100AX300S Technical Specifications
| Model | Airtac SAID100 Double Rod Cylinder SAID100AX300S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 300 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID100 Double Rod Cylinder SAID100AX300S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×300 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID100 Double Rod Cylinder SAID100AX300S Is Used
Symmetric Force Transfer
Drives a shuttle mechanism where the 3681 N push and pull forces must be perfectly matched to prevent drive train backlash or uneven acceleration.
Twin-Station Actuation
Mounts a machining fixture on the front rod and a secondary cam on the rear rod to trigger a separate process at the exact same stroke interval.
Anti-Rotation Slides
Utilizes the through-rod design to guide heavy loads across a 300 mm stroke without the rotational twisting common to single-rod actuators.
Is the Airtac SAID100 Double Rod Cylinder SAID100AX300S the Right Cylinder?
Choose this 100 mm bore when a 80 mm bore (2268 N at 0.5 MPa) lacks the thrust for your symmetric transfer task, but you want to avoid the heavier 125 mm class. The double-rod design is selected over a single-rod SAI when the application demands dual-side guidance, anti-rotation stability, or rear-rod actuation. It uses the reduced SAID mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and PT tapered ports.
At a 300 mm stroke, the unsupported rod length increases side-load risks and rod-bearing bending; always use an external guide to prevent premature wear. Note that a plain SAID does not hold its load when air is lost or the valve is centered—the piston drifts. For dead-air position holding, consider an external rod lock, SAIL, or BSAID clamp-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID100 Double Rod Cylinder SAID100AX300S FAQ
It provides 3681 N of force at 0.5 MPa, 5153 N at 0.7 MPa, and 6626 N at 0.9 MPa. Because it is a double-rod cylinder, this force is identical in both extend and retract directions.
Yes, the SAID100X300-S is dimensionally interchangeable per ISO 15552, serving as a drop-in replacement for other ISO 15552 double-rod profile cylinders. It uses PT ports and works with AirTAC CMSE and DMSE sensors.
