Airtac SAID50 Double Rod Cylinder SAID50X115S
The AirTAC Airtac SAID50 Double Rod Cylinder SAID50X115S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 115mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ50 mm
- Stroke115 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID50 Double Rod Cylinder SAID50X115S
The AirTAC SAID50X115-S is a double-acting, double-rod ISO 15552 profile cylinder featuring a through-rod that exits both end covers. Because the rod occupies an equal area on both sides of the piston, the annulus area is identical in both directions, yielding a perfectly symmetric output of 825 N at 0.5 MPa for extend and retract strokes. This 115 mm stroke is a non-standard, made-to-order length that requires rear-rod clearance during machine layout.
Equipped with a magnetic piston (-S), this carbon-steel rod variant directly supports AirTAC CMSE reed and DMSE solid-state sensors via the dual-side extruded aluminum barrel grooves. The PT tapered port threads ensure a tight pneumatic seal, while the twin-rod design provides superior anti-rotation guidance for demanding transfer tasks.
Airtac SAID50 Double Rod Cylinder SAID50X115S Technical Specifications
| Model | Airtac SAID50 Double Rod Cylinder SAID50X115S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø50 mm |
| Stroke | 115 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID50 Double Rod Cylinder SAID50X115S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 50 | Bore size in mm. |
| ×115 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID50 Double Rod Cylinder SAID50X115S Is Used
Symmetric Transfer Unit
Drives a dual-sided pick-and-place gantry where the equal 825 N force both ways ensures stable, jerk-free material transfer without momentum imbalances.
Rear-Rod Cam Actuation
Uses the protruding rear rod to trigger a mechanical limit flag or secondary cam mechanism, keeping the primary work tool and sensor feedback perfectly synchronized.
Anti-Rotation Guide Slide
Leverages the twin-rod architecture to prevent piston rotation, guiding a heavy vertical slide payload that would otherwise bind in a single-rod setup.
Is the Airtac SAID50 Double Rod Cylinder SAID50X115S the Right Cylinder?
Select this 50 mm bore cylinder when an application demands equal push and pull forces, such as 825 N at 0.5 MPa, alongside strict anti-rotation control. If your mechanism requires higher thrust, stepping up to the 63 mm bore yields 1402 N both ways; if less force is needed, the 40 mm bore provides 528 N. The defining advantage of this SAID over a single-rod SAI is the rear protruding rod, which can mount a secondary cam, position flag, or drive a second mechanism simultaneously.
This model includes the -S magnet for position sensing and uses a PT G1/4 port. It is dimensionally interchangeable per ISO 15552 for drop-in replacement of other double-rod profile cylinders. Note that a plain SAID does not hold its load when air is removed; if the valve is centered or pressure drops, the piston drifts. For position holding, consider a SAIL lock cylinder, a BSAID clamp-lock, or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID50 Double Rod Cylinder SAID50X115S FAQ
Because the double-rod design has the rod area subtracted from both sides of the piston, the extend and retract forces are equal. It generates 825 N at 0.5 MPa, 1154 N at 0.7 MPa, and 1484 N at 0.9 MPa in both directions.
Yes, the SAID50X115-S is dimensionally interchangeable per ISO 15552 profile cylinder standards. It uses the standard mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and serves as a drop-in replacement for other ISO 15552 double-rod cylinders.
