Airtac SAID80 Double Rod Cylinder SAID80X10
The AirTAC Airtac SAID80 Double Rod Cylinder SAID80X10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø80mm bore and 10mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke10 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAID80 Double Rod Cylinder SAID80X10
The AirTAC SAID80X10 is a double-acting, double-rod ISO 15552 profile cylinder with a 10 mm stroke. Because a carbon steel rod exits both end covers, the annulus area is identical on extend and retract, yielding exactly 2268 N of force each way at 0.5 MPa. The short 10 mm travel makes it highly responsive for clamping or ejecting tasks within a 30-800 mm/s speed range.
This through-rod design lets you mount the primary workpiece on the front while attaching a cam or position flag to the rear. It features adjustable air cushions at both ends and dual sensor grooves. Note that without a magnet (-S), it cannot host CMSE or DMSE switches.
Airtac SAID80 Double Rod Cylinder SAID80X10 Technical Specifications
| Model | Airtac SAID80 Double Rod Cylinder SAID80X10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAID80 Double Rod Cylinder SAID80X10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAID80 Double Rod Cylinder SAID80X10 Is Used
Symmetric Transfer
Drives a dual-sided transfer mechanism where the equal 2268 N force both ways ensures balanced pushing and pulling across a short 10 mm stroke.
Anti-Rotation Slide
The twin carbon steel rods exiting both ends guide the load against twisting, making it ideal for precision short-stroke slide actuation.
Rear-Cam Ejection
Mount the work tool on the front rod and a mechanical cam on the rear rod to trigger a secondary ejection sequence simultaneously.
Is the Airtac SAID80 Double Rod Cylinder SAID80X10 the Right Cylinder?
Select this 80 mm bore when an application requires symmetric force and short movement, as the twin rods prevent load rotation better than a single-rod SAI. If you need less force, the 63 mm bore provides 1402 N both ways at 0.5 MPa. For heavier loads, the 100 mm bore offers 3681 N. SAID uses a reduced mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and omits FB and CA brackets.
The PT G3/8 porting matches the bore size. Remember that a plain SAID does not hold a load if air pressure drops; the cushions only decelerate the piston near stroke end. For position holding, consider an external rod lock or the BSAID clamp-lock variant. It is dimensionally interchangeable per ISO 15552.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAID80 Double Rod Cylinder SAID80X10 FAQ
The double-rod design means push and pull forces are equal. It delivers 2268 N both directions at 0.5 MPa, 3175 N at 0.7 MPa, and 4082 N at 0.9 MPa.
Yes, it is dimensionally interchangeable per ISO 15552. However, the SAID series uses a reduced mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2) and omits FB, CA, CB, and CR brackets.
