Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S
The AirTAC Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S
The AirTAC SAIJ200X100-10-S is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. With a nominal 100mm stroke and a 10mm adjustment range, it provides a usable travel window of 90-100mm. This allows you to fine-tune the retract end position at commissioning without adding external stops. It delivers substantial thrust, offering 15708N push and 15080N pull at 0.5MPa.
This SKU is equipped with a SUS420J2 stainless steel rod (option A) for improved corrosion resistance and includes a magnet (-S) for position sensing. The extruded aluminum barrel features sensor grooves on both sides, compatible with AirTAC CMSE reed and DMSE solid-state switches. It uses a G3/4 port and operates at speeds from 30-500mm/s.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S Technical Specifications
| Model | Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S Is Used
Heavy Press Tuning
Dial in the exact 90-100mm travel window during heavy press commissioning to perfect the end position without swapping cylinders.
Product Size Changeover
Quickly adjust the retract stop on a packaging line to handle varying product sizes on the fly without bolting on external stops.
Machine Setup
Fine-tune the end position during initial machine setup to compensate for mechanical tolerances in heavy 200mm bore assemblies.
Is the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S the Right Cylinder?
Selecting this 200mm bore adjustable cylinder makes sense when your machine setup requires variable end stops or precise product-size changeovers on a line. Rather than stepping down to a 160mm bore that provides 10053N push at 0.5MPa, the 200mm bore offers maximum thrust up to 15708N at 0.5MPa for heavy loads. The rear adjuster acts as a travel stop to decelerate the stroke end, but it is not a lock; a plain SAIJ does not hold position without live air. For load-holding without pressure, consider an external rod lock, or use SAIL or BSAI cylinders.
To match this ISO 15552 replacement, specify: 200mm bore, 100mm stroke, 10mm adjustment, PT tapered port, Basic/FA/LB/TC/FTC/TCM1/TCM2 mounting, and the -S magnet. Because the stroke is 100mm, side-load is minimal, but long unsupported loads still need an external guide.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-10S FAQ
At 0.5MPa, this 200mm bore cylinder provides 15708N of push force and 15080N of pull force. At 1.0MPa, it delivers a maximum of 3204 kgf.
The rear adjuster screw lets you shorten the effective stroke by up to 10mm, creating a 90-100mm usable travel window. It acts as a mechanical stop to tune the end position, but it does not lock the load without live air.
