Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB
The AirTAC Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB is a genuine double-acting COMPACT cylinder with a piston rod out BOTH ends (Ø100mm bore, 110mm stroke). The through-rod resists twisting and lets you drive a tool on one end while a switch or dog reads position on the other — with identical force in both directions.
- BoreØ100 mm
- Stroke110 mm
- Port sizePT3/8
- Acting typeDouble acting, double rod
- Rod threadM18×1.5 (F) / M26×1.5 (B)
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB
The AirTAC SDAD100X110SB is a double-acting, double-rod compact cylinder engineered for heavy-duty symmetrical motion. Because the 32 mm through-rod occupies both internal chambers, the effective annular area remains identical in both directions. This geometry yields an equal push and pull force of 3524.9 N at 0.5 MPa, ensuring perfectly balanced actuation for heavy payloads. The short riveted body drastically saves axial mounting depth where a larger profile cylinder would fail to fit.
This specific configuration includes a built-in piston magnet for AirTAC reed or electronic switches, plus male M26x1.5 rod threads on both ends. End-of-stroke deceleration relies on a fixed NBR bumper rather than an adjustable air cushion. Operating pressure spans 0.15 to 1.0 MPa, and the piston speed ranges from 30 to 500 mm/s.
Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB Technical Specifications
| Model | Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB |
|---|---|
| Series | SDAD compact double-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting, rod both ends |
| Port size | PT3/8 |
| Rod end thread | M18×1.5 female / M26×1.5 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
| Max standard stroke | Up to 120 mm |
Because a rod occupies both cylinder chambers, the effective area — and therefore the force — is identical in both directions. Specifications follow the official AirTAC SDAD datasheet.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 3525 N |
| 0.7 MPa | 4935 N |
| Max (@1.0 MPa) | 719 kgf |
Force uses the annular (rod-side) area on both strokes, so extend and retract match. Actual usable force is lower than theoretical due to friction. Size with a safety margin.
Model Code: Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB
| SDAD | Compact double-acting cylinder, rod out both ends. |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rods (omit = female thread). |
Thread: PT standard. Related SDA-family variants: SDA (single rod), SSA/STA (single acting), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB Is Used
Heavy Press Lift Table
Drives a 175 kg vertical lift platform. The equal 3524.9 N force both up and down prevents gravitational sag, while the male M26x1.5 rods secure heavy tooling flanges.
Symmetric Gripper Actuator
Powers a dual-jaw clamping mechanism. The through-rod geometry resists twisting under offset loads, maintaining precise parallel grip on large forged parts.
Dual-End Transfer Pusher
Mounts a pusher blade on one rod end and a magnetic dog on the opposite end. The 110 mm stroke transfers heavy pallets while tracking position via the built-in magnet.
Is the Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB the Right Cylinder?
When sizing this model, compare its 3524.9 N output at 0.5 MPa against the adjacent bore. Stepping down to the SDAD80 provides 2267.8 N, which may be insufficient for high-mass tooling, whereas the 100 mm bore offers a safe working load of roughly 2115 N (about 60% of its 0.5 MPa capacity) and a vertical lift capacity of approximately 179.7 kg with a 2:1 safety margin. The through-rod design resists twisting and allows mounting a tool on one end while tracking position with a switch on the opposite end.
Confirm the 100 mm bore, 110 mm stroke, and PT3/8 porting fit your envelope. The male M26x1.5 threads and built-in magnet are present per the SB option codes. Note that a plain cylinder does not hold its load on air loss or valve centring; the piston drifts and the fixed NBR bumper only decelerates near stroke end. For load holding without live pressure, install an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need equal force both directions?
- ✓ Anti-rotation / dual-end mounting?
- ✓ Space for a rod that exits both ends
- ✓ Port/thread type (PT)
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Leave clearance for the rod exiting both ends.
- check Avoid side load on either rod end.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAD Double Rod Slim Cylinder SDAD100X110SB FAQ
The double-rod design provides equal force in both directions: 3524.9 N at 0.5 MPa and 4934.8 N at 0.7 MPa. The theoretical maximum is 719 kgf at 1.0 MPa. The maximum operating pressure is 1.0 MPa, with a proof pressure of 1.5 MPa.
Yes. The 32 mm through-rod exits both ends with male M26x1.5 threads, allowing you to mount a tool on one side and a dog for a reed or electronic switch on the other. The built-in magnet enables position sensing via standard AirTAC magnetic switches.
