Airtac 2-Way Solenoid Valve 2W030-08-F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W030-08-F Solenoid Valve Specifications
- Model: 2W030-08-F
- Type: 2-position 2-way, normally closed (direct acting)
- Port size: PT3/8 (G3/8 optional)
- Thread standard: ISO 228/ISO 6149 compliant
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Max flow rate: 850 l/min (Cv=1.2 at 7 bar)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 4.5W / AC: 5.5VA
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 0.45 kg (with coil)
- Dimensions: 58mm(L) × 45mm(W) × 53mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Ambient temperature range: -5℃ to 80℃ (with no freezing)
- Fluid temperature range: 0℃ to 60℃
- Protection rating: IP67 (coil)/IP40 (valve body)
- Port orientation: Horizontal/vertical (bidirectional mounting)
High-flow compact solenoid valve featuring dual-position direct drive mechanism for precise air control in medium-pressure systems. Enhanced HNBR seals provide extended service life in oil-mist lubrication environments. Optimized flow path design reduces pressure drop by 18% compared to previous generation models.
- Pneumatic cylinder directional control in assembly lines
- Vacuum generator switching in material handling systems
- Air blow cleaning circuits in CNC machining centers
- Inflation/deflation control in packaging machinery
- Compressed air distribution in automotive brake test rigs
Installation guidelines:
For horizontal piping, install with coil facing upward to prevent debris accumulation.
Use shock-absorbing mounting brackets in high-vibration environments.
Apply 2-3 drops of ISO VG32 turbine oil monthly for maintenance in continuous operation systems.
| Property | Property Value |
|---|---|
| sku | 2W030-08-F |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
