Airtac 2-Way Solenoid Valve 2W200-20-E
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W200-20-E Solenoid Valve Technical Details
- Model: 2W200-20-E
- Type: 2-position 2-way direct-acting (universal port design)
- Port size: G1/4 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage tolerance: ±10% (Options: DC12V/24V, AC110V/220V 50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (at rated voltage)
- Seal material: High-grade HNBR (-20℃ to 120℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Flow coefficient (Cv): 1.2
- Port thread depth: 12mm (with O-ring groove)
- Weight: 285g ±5g (with coil)
- Dimensions: 54mm(L) × 40mm(W) × 71mm(H)
- Protection rating: IP67 (coil assembly)
- Electrical connection: DIN43650 Form A connector
High-flow 2/2-way valve featuring bi-directional flow capability and zero pressure differential operation. The full-bore design minimizes pressure drop (ΔP ≤0.02MPa at 5L/min), with brass body construction providing superior corrosion resistance. Includes manual override function for system debugging.
- CNC machine tool coolant control systems
- Plastic injection molding machine pneumatics
- Semiconductor wafer handling equipment
- High-cycle packaging line actuators (≥5 million cycles rating)
- Compressed air distribution manifolds
Installation guidelines:
Mount in any orientation except coil-down position. Use 5Nm torque for port connections.
For pulsation-sensitive systems, install 20cm downstream of pressure regulator.
Requires 5μm filtration (40μm minimum without lubricant).
| Property | Property Value |
|---|---|
| sku | 2W200-20-E |
| Port Size | BSPT 3/4 |
| Flow Aperture | <20mm> |
| Coil Voltage | AC24V |
