Airtac 2KS Series Fluid Control Valve 2KS03006CI
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS Series Fluid Control Valve 2KS03006CI Technical Details
- Model: 2KS03006CI
- Type: 2-position 3-way (3/3) closed-center solenoid valve
- Port configuration: 3 ports (P: pressure, A/B: outlets, R: exhaust)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Seal materials: NBR (standard), optional Viton for high-temp
- Ambient temperature: -5℃ to 60℃ (NBR), -5℃ to 120℃ (Viton)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Durability: ≥10 million cycles
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 480g ±5% (with coil)
- Dimensions: 76mm(L) × 42mm(W) × 88mm(H)
- Mounting: ISO 4400 standard interface
High-flow proportional control valve with zero-leakage design, featuring brass body construction with electroless nickel plating for corrosion resistance. The balanced spool structure ensures stable operation under pressure fluctuations. Requires 5μm filtered compressed air (lubricated or non-lubricated). Compatible with ISO 15407-1 manifolds.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging systems
- Coolant flow regulation in CNC machining centers
- Process gas control in semiconductor manufacturing
- Beverage dispensing system automation
Installation guidelines:
Mount with torque ≤1.5N·m using M5 mounting screws. Maintain ambient humidity
below 85% RH. For vertical mounting, ensure exhaust port faces downward.
Allow 15mm clearance for heat dissipation during continuous operation.
Note:
Not compatible with phosphate ester-based lubricants. When using in explosive
atmospheres, pair with appropriate explosion-proof coil housing (optional).
| Property | Property Value |
|---|---|
| sku | 2KS03006CI |
| Port Size | PT1/8 |
| Flow Aperture | PT1/8 |
| Coil Voltage | AC 110V |
