Airtac 2KS Series Fluid Control Valve 2KS03006F
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS Series Fluid Control Valve 2KS03006F Technical Details
- Model: 2KS03006F
- Type: 2-position 3-way direct-acting solenoid valve
- Port configuration: 3 ports (P: pressure, A: outlet, R: exhaust)
- Port size: G1/8 (ISO228/1 standard)
- Thread type: Parallel (BSPP)
- Operating pressure range: 0.05–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Ambient temperature: -5℃ to 80℃ (no freezing)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dustproof & waterproof)
- Weight: 320g ±5g (including coil)
- Dimensions: 58mm (L) × 34mm (W) × 72mm (H)
- Mounting orientation: Any (horizontal/vertical)
- Port alignment: Linear configuration with 18mm center spacing
High-flow 2KS03006F features a unique spool-less design with metal-to-metal sealing, enabling 2 million cycle durability. Optimized for viscous fluids and air-oil mist environments. The copper-free aluminum body with anodized treatment resists chemical corrosion. Includes surge protection diode and manual override button.
- Hydraulic unit directional control in CNC turret systems
- Coolant flow switching for multi-spindle machining centers
- Lubrication system sequencing in die-casting machines
- Pneumatic clamping control for injection molding
- Vacuum/pressure alternation in semiconductor wafer handling
Operational guidance:
Use 7-10Nm torque during port connection. For oil control,
install downstream filter (25μm or finer). Avoid rapid
pressure fluctuations exceeding 0.3 MPa/sec. Lubricate seals
with ISO VG32 oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | 2KS03006F |
| Port Size | PT1/8 |
| Flow Aperture | PT1/8 |
| Coil Voltage | DC12V |
