Airtac 2SL Fluid Control Valve 2SL05010EI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL05010EI Fluid Control Valve Technical Details
- Model: 2SL05010EI
- Type: 5-port/3-position closed center (pneumatic directional control)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.2–1.0 MPa (29–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (including solenoid coil)
- Dimensions: 62mm(L) × 45mm(W) × 78mm(H) (body only)
- Port-to-port spacing: 25mm (horizontal), 18mm (vertical)
- Seal material: FKM fluorocarbon (standard), optional HNBR
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Flow rate: 750 NL/min (at 0.5 MPa)
- Response time: ≤25ms (at rated voltage)
- Protection rating: IP67 (solenoid), IP40 (valve body)
- Manual override: Built-in emergency switch (push-button type)
High-flow proportional control valve with closed-center functionality, featuring precision-machined spool and dual pressure balancing channels. The aluminum alloy body undergoes multi-stage anodization for corrosion resistance. Includes surge protection circuitry and LED status indicator. Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery tension regulation systems
- Semiconductor wafer handling robotics
- Food processing pneumatic actuators (HNBR seal version)
Installation guidelines:
Mount with vibration-damping gaskets when used in high-frequency environments (>15Hz).
Maintain minimum 20mm clearance below valve for condensate drainage. Lubricate spool
quarterly with ISO VG32 pneumatic oil if using non-lubricated air systems.
| Property | Property Value |
|---|---|
| sku | 2SL05010EI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC24V |
