Airtac 2V Fluid Control Valve 2V130-15-A
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V130-15-A Fluid Control Valve Technical Details
- Model designation: 2V130-15-A
- Valve type: 2-position 3-way (2V series), normally closed
- Port configuration: 1/4" BSPP (G1/4) female threads
- Pressure range: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 850 l/min (Cv=1.2) at 0.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Seal materials: HNBR (hydrogenated nitrile) main seals, FKM (Viton®) optional
- Ambient temperature: -5℃ to 80℃ (no freeze)
- Weight: 220g ±5% (excluding accessories)
- Dimensions: 56mm(L) × 34mm(W) × 66mm(H) (body only)
- Mounting orientation: Any (recommended horizontal for optimal drainage)
- Protection standard: IP67 (coil), IP40 (valve body)
- Expected lifespan: 10 million cycles (under rated conditions)
High-flow proportional control valve with brass body construction and electromagnetic direct drive mechanism. Features zero-pressure differential start capability and integrated manual override. The optimized spool design reduces hysteresis to ≤3% FS. Requires 5μm filtration (40μm for intermittent use) with lubricated or non-lubricated air.
- Beverage filling line pressure regulation
- Plastic injection molding machine clamp control
- Automated textile machinery tension systems
- Semiconductor wafer handling vacuum/pressure switching
- Pharmaceutical blister packaging air circuits
Maintenance advisory:
Perform monthly air purge through test port. Avoid continuous
duty cycles exceeding 90% ON-time without heat sink attachment.
Use thread sealant (PTFE tape prohibited) during installation.
| Property | Property Value |
|---|---|
| sku | 2V130-15-A |
| Port Size | PT 1/2 |
| Flow Aperture | 13mm |
| Coil Voltage | AC220V |
