Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA0806-1N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA0806-1N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA0806-1N
- Type: Self-compensating hydraulic buffer (oil type)
- Capacity: 0.35 N·m/cycle
- Max. impact energy: 2.5 J/cycle
- Max. impact speed: 2.0 m/s
- Stroke: 6 mm (±1 mm)
- Adjustment method: Automatic viscosity compensation
- Buffer force range: 50-500 N (self-regulating)
- Operating temperature: -10℃ to +80℃
- Fluid viscosity range: 10-500 cSt
- Housing material: Steel with chrome plating
- Seal material: NBR (nitrile rubber)
- Weight: 0.35 kg ±5%
- Dimensions: 80mm(L) × 30mm(W) × 30mm(H)
- Mounting thread: M8×1.25
- Surface treatment: Anti-corrosion coating
- Reaction force: ≤200 N at max. capacity
Precision-engineered hydraulic buffer featuring automatic viscosity compensation that maintains consistent damping performance despite temperature fluctuations. The ACA series' unique valve design enables self-regulation of buffer force without manual adjustments, with a fail-safe mechanism preventing oil leakage during overload conditions. Optimized for high-cycle applications requiring ≤50,000 operations/day.
- Robotic arm end-effector shock absorption
- High-speed packaging machine stoppers
- CNC tool changer mechanisms
- Automated conveyor sorting systems
- Stamping machine overstroke protection
- Semiconductor handling equipment
Installation guidelines:
Mount vertically with arrow marking facing impact direction. Allow 20mm clearance behind buffer for heat dissipation.
Perform 5-10 test cycles before full operation. Relubricate every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ACA0806-1N |
| External Thread | M8 |
| Stroke | <6mm> |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Without Bumper Cap |
