Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA0806-2N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA0806-2N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model Code: ACA0806-2N
- Type: Auto-compensating oil-filled shock absorber
- Bore Size: 8mm (M8x1.0 thread)
- Stroke: 6mm (±1mm adjustable)
- Max. Energy Absorption: 0.8 Nm/stroke
- Impact Velocity Range: 0.2-1.5 m/s
- Operating Temp: -10℃ to +80℃
- Return Time: ≤1.5s (after full compression)
- Housing Material: Anodized aluminum alloy
- Rod Material: Hardened stainless steel
- Seal Type: Multi-lip NBR seals
- Weight: 530g ±5%
- Dimensions: 48mm(L) × 32mm(W) × 80mm(H) (including mounting flanges)
- Mounting Pattern: 25mm center-to-center hole spacing
- Oil Viscosity: ISO VG15 hydraulic fluid (pre-filled)
- Impact Force: 50-300N adjustable via internal valve
Self-regulating hydraulic damper with temperature-compensated viscosity control, featuring wear indication through visible stroke reduction. The 2N suffix indicates nickel-plated corrosion resistance for humid environments. Integrated bypass channel prevents oil starvation during high-frequency cycling.
- CNC tool changer arm deceleration
- Robotic pick-and-place end effector stabilization
- Packaging machine gripper head damping
- Conveyor system end-stop impact absorption
- Semiconductor wafer handling equipment
Installation guidelines:
Mount perpendicular to impact direction with M5x0.8 screws (12N·m torque max).
Allow 2-3mm free play before initial contact. Perform 10-15 test strokes
to prime seals before full operation. Check oil weep hole orientation (must face downward).
| Property | Property Value |
|---|---|
| sku | ACA0806-2N |
| External Thread | M8 |
| Stroke | <6mm> |
| Speed Code | Medium Speed (Medium Load) |
| Bumper Cap Code | Without Bumper Cap |
