Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA0806-3
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA0806-3 Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA0806-3
- Type: Automatic oil pressure buffering with self-compensation
- Max. absorbed energy: 0.7 N·m/cycle
- Max. impact velocity: 2.0 m/s
- Stroke length: 6 mm (±1 mm)
- Adjustment range: 20%-100% of rated capacity
- Max. impact force: 300 N
- Mounting style: Threaded body (M8×1.25)
- Operating temperature: -10℃ to 80℃
- Body material: Hard-anodized aluminum alloy
- Piston rod: Chrome-plated steel
- Oil type: ISO VG32 hydraulic fluid
- Weight: 280 g ±5g
- Dimensions: Ø28mm × 80mm (Diameter × Length)
- Return time: <0.8 sec after full compression
- Cyclic life: >1,000,000 cycles (under rated load)
The ACA0806-3 features dynamic viscosity compensation technology that automatically adjusts damping force based on impact velocity and temperature changes. Its multi-stage buffering design combines orifice restriction and chamber compression phases, achieving 92% energy conversion efficiency. The hardened stainless steel wear ring ensures minimal friction loss (<0.02μ) during piston movement.
- High-speed pick-and-place robot end effectors
- CNC machine tool automatic door mechanisms
- Packaging line conveyor diverters
- Automated warehouse stacker cranes
- Die-casting machine ejection systems
Installation protocol:
Mount vertically with impact direction aligned to piston axis. Allow 1-2mm clearance between
the striker and piston head. Perform 5-10 test strokes before full operation. Relubricate every
50,000 cycles using ISO VG32 equivalent oil.
Critical note:
Avoid angular impacts exceeding 3° deviation. Not suitable for continuous side load
applications. Maximum allowable lateral force: 15N. Replace buffer if oil leakage exceeds
0.05ml/10,000 cycles.
| Property | Property Value |
|---|---|
| sku | ACA0806-3 |
| External Thread | M8 |
| Stroke | <6mm> |
| Speed Code | Low Speed (Heavy Load) |
| Bumper Cap Code | Plastic Bumper Cap |
