Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1006-A
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1006-A Auto-Compensated Hydraulic Shock Absorber Specifications
- Model: ACA1006-A
- Type: Standard auto-compensating hydraulic damper
- Max. Energy Absorption: 0.45 Nm/cycle
- Impact Velocity Range: 0.2-1.5 m/s
- Stroke: 6 mm (±1 mm)
- Shaft Diameter: 10 mm (hardened steel)
- Operating Temperature: -20℃ to +80℃
- Housing Material: Anodized aluminum alloy
- Seal Material: High-grade polyurethane/NBR hybrid
- Weight: 0.35 kg (without accessories)
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Mounting Thread: M10×1.25 (standard)
- Max. Side Load Capacity: 50 N
- Recovery Time: ≤0.2 sec after impact
- Viscosity Grade: ISO VG32 hydraulic oil
- Installation Torque: 15-20 N·m
Self-regulating hydraulic damper with temperature-compensated orifice technology maintains consistent damping force across operating conditions. Features dual-stage sealing system with integrated wiper to prevent particulate ingress. The chrome-plated piston rod and anti-rotation design ensure smooth linear motion even under misalignment conditions.
- High-cycle injection molding machine ejectors
- Automated conveyor sorting gates
- CNC tool changer mechanisms
- Industrial robot end-effector cushioning
- Packaging machine rotary index tables
- Stamping press over-travel protection
Installation guidelines:
Align within 0.5° angular tolerance during mounting. Perform initial 50-100 test cycles at 50% load capacity before full operation. Replace damping oil every 500,000 cycles or annually. Avoid side impacts exceeding 20% of axial load rating.
| Property | Property Value |
|---|---|
| sku | ACA1006-A |
| External Thread | M10 |
| Stroke | <6mm> |
| Speed Code | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Bumper Cap Code | Plastic Bumper Cap |
