Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1007-2N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1007-2N Standard Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1007-2N
- Type: Single-cylinder automatic compensation type
- Max. absorbed energy: 1.47 J/cycle
- Max. impact velocity: 1.5 m/s
- Effective weight capacity: 0.5-35 kg
- Adjustment method: Self-compensating oil control
- Stroke length: 20 mm
- Rod diameter: Φ10 mm
- Operating temperature: -20℃ to +80℃
- Fluid medium: ISO VG32 hydraulic oil (pre-filled)
- Housing material: Carbon steel with nickel plating
- Seal material: HNBR (Hydrogenated Nitrile)
- Mounting orientation: Horizontal or vertical
- Weight: 520 g ±2%
- Dimensions: 58mm(L) × 32mm(W) × 32mm(H)
- Mounting torque: 14-16 N·m (M8 thread)
- Replacement cycle: 1 million strokes (under rated load)
Precision-engineered hydraulic damper with automatic viscosity compensation, maintaining consistent damping force across temperature variations. Features zero-leakage seals and impact-resistant tungsten carbide piston rod. Integrated dust wiper extends service life in contaminated environments.
- High-speed pick-and-place robot end effectors
- CNC machine tool automatic door mechanisms
- Packaging line product stoppers
- Automated warehouse shuttle dampening
- Semiconductor wafer handling equipment
Installation tip:
Align impact direction with buffer axis within ±2° deviation. Perform 5-10 test strokes
before full operation to distribute oil evenly. Re-tighten mounting bolts after 24hrs of initial use.
| Property | Property Value |
|---|---|
| sku | ACA1007-2N |
| External Thread | M10 |
| Stroke | 7mm |
| Speed Code | Medium Speed (Medium Load) |
| Bumper Cap Code | Without Bumper Cap |
