Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1210-2N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1210-2N Standard Auto-Compensation Hydraulic Shock Absorber Specifications
- Model: ACA1210-2N
- Type: Auto-compensating adjustable hydraulic damper
- Buffer force range: 50-450 N (adjustable)
- Stroke: 10 mm (±1 mm)
- Shaft diameter: Φ12 mm
- Mounting style: Front flange with M10×1.25 thread
- Material: Chrome-plated piston rod (SCM435 steel), Aluminum alloy body
- Operating temperature: -10℃ to 80℃
- Max. impact speed: 2.0 m/s
- Max. energy absorption: 2.5 J/cycle
- Oil type: ISO VG32 hydraulic fluid
- Weight: 385 g ±5%
- Dimensions: 68mm(L) × 32mm(W) × 32mm(H)
- Protection rating: IP65 (dust-tight & low-pressure water jet resistant)
- Recoil time: ≤1.2 seconds (at 20℃)
Self-compensating hydraulic damper with oil temperature compensation mechanism, featuring automatic viscosity adjustment for consistent damping performance across temperature variations. The dual-seal structure (primary PTFE + secondary NBR) ensures long-term leak resistance. Includes dust wiper for harsh environments.
- High-speed punching machine ram deceleration
- Industrial robot end-effector vibration control
- Automated warehouse stacker crane positioning
- CNC tool changer impact absorption
- Packaging line product stopper mechanisms
Installation note:
Mount vertically with impact direction aligned to piston axis. Perform initial 50-100 test cycles before full operation.
Relubricate sliding surfaces with ISO VG32 oil every 500,000 cycles or 6 months.
| Property | Property Value |
|---|---|
| sku | ACA1210-2N |
| External Thread | M12 |
| Stroke | <10mm> |
| Speed Code | Medium Speed (Medium Load) |
| Bumper Cap Code | Without Bumper Cap |
