Airtac ACA Standard Automatic Compensation Hydraulic Shock Absorber ACA1215-1N
2. Monolithic structure withstands extreme pressure; Fully threaded external housing facilitates installation and adjustment while maintaining superior heat dissipation.
3. High-hardness stainless steel spindle enhances impact resistance and corrosion resistance, ensuring reliable operation in harsh operating conditions.
4. Specialized oil-injection technology ensures consistent damping performance and operational stability.
5. Compact profile design with industry-leading energy absorption capacity.
6. Proprietary lubricant as damping medium delivers stable buffering performance across wide temperature ranges (-20°C to +80°C).
Category: Hydraulic Shock Absorbers | Brand: AirTAC | Series: ACA Self-Compensating
AirTAC ACA1215-1N Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACA1215-1N
- Type: Standard automatic compensation oil buffer
- Max. impact energy: 156 J
- Max. impact velocity: 2.0 m/s
- Stroke length: 25 mm
- Rod diameter: 15 mm
- Mounting hole spacing: 40±0.2 mm
- Operating temperature: -10℃ to 80℃
- Fluid viscosity range: 15-500 cSt
- Housing material: S45C steel with black oxide coating
- Seal material: HNBR (Hydrogenated Nitrile)
- Weight: 0.85 kg
- Dimensions: 130mm(L) × 50mm(W) × 50mm(H)
- Protection rating: IP64
- Re-oiling cycle: 1 million cycles (auto-compensation)
Precision-engineered hydraulic damper with automatic oil compensation system, featuring wear-resistant tungsten carbide piston rings. The dual-stage buffering mechanism provides smooth deceleration across varying loads. Includes anti-rotation design for stable operation in high-vibration environments (up to 15Hz).
- High-speed punching press counterbalance systems
- Automated palletizer end-of-stroke damping
- CNC machine tool carriage deceleration
- Robotic arm joint shock absorption
- Elevator car emergency stopping mechanisms
Installation guidelines:
Mount vertically with rod facing downward for optimal oil circulation.
Perform initial 50 test strokes before full operation.
Relubricate every 6 months under continuous use (2000+ cycles/day).
- Maximum side load capacity: ≤5% of axial force
- Requires 2mm minimum clearance around moving parts
- Use ISO VG15-68 hydraulic oil only
| Property | Property Value |
|---|---|
| sku | ACA1215-1N |
| External Thread | M12 |
| Stroke | <15mm> |
| Speed Code | High Speed (Light Load) |
| Bumper Cap Code | Without Bumper Cap |
