Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X10S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X10S Rotary Clamping Cylinder Specifications
- Model: QCKL12X10S
- Type: Double-acting rotary clamp cylinder
- Bore size: 12mm
- Stroke: 10mm
- Rotation angle: 90° ±5° (standard)
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Mounting style: Side/Flange mounting (M5 threaded holes)
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Weight: 0.45kg ±5%
- Dimensions: 100mm(L) × 32mm(W) × 60mm(H)
- Rod thread: M6×1.0
- Rotation torque: 0.8N·m (at 0.5MPa)
- Repeat positioning accuracy: ±0.05mm
- Protection rating: IP40
- Air port size: M5×0.8 (Rc1/8 compatible)
Compact rotary clamping cylinder with integrated precision guide mechanism, designed for high-accuracy positioning and secure workpiece retention. Features anti-rotation design during clamping action and wear-resistant surface treatment. Requires filtered air (40μm) with recommended lubrication (ISO VG32).
- Robotic end-effector tool changers
- CNC machine fixture positioning
- Automated assembly line clamping
- PCB handling and soldering jigs
- Medical device manufacturing fixtures
Operation note:
Ensure proper alignment of clamping surfaces before activation.
Maximum side load ≤15N. Lubricate guide shafts every 500,000 cycles
using silicone-free grease. Avoid continuous rotation beyond specified angle.
| Property | Property Value |
|---|---|
| sku | QCKL12X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
