Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X10SM
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X10SM Rotary Clamping Cylinder Specifications
- Model: QCKL12X10SM
- Type: Double-acting rotary clamping cylinder with magnetic piston
- Bore size: 12mm
- Stroke: 10mm
- Rotation angle: 90° ±5°
- Operating pressure: 0.1–0.8 MPa
- Max torque output: 0.5 N·m (at 0.6 MPa)
- Piston speed: 50–500 mm/s
- Mounting style: Standard flange/Foot mounting
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.28 kg
- Dimensions: 62mm(L) × 42mm(W) × 42mm(H)
- Repeat positioning accuracy: ±0.5°
- Protection rating: IP54 (standard), IP67 (optional w/wiper)
A precision rotary clamping cylinder combining linear thrust and angular positioning. Features integrated T-slot for tooling plate attachment and built-in cushioning for smooth rotation. The SM variant includes magnetic piston for position feedback compatibility with inductive sensors. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- PCB fixture positioning in SMT machines
- Medical device assembly jigs
- Robotic end-effector tool changers
- Automotive component welding fixtures
- Optical lens polishing equipment
| Property | Property Value |
|---|---|
| sku | QCKL12X10SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
