Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X20S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X20S Rotary Clamping Cylinder Specifications
- Model: QCKL12X20S
- Type: Double-acting rotary clamp cylinder
- Bore size: Ø12mm
- Stroke: 20mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (standard)
- Cushioning: Adjustable rubber bumper
- Body material: Aluminum alloy (anodized)
- Rod material: Stainless steel (SUS304)
- Rotation angle: 90° ±5°
- Clamping force: 30N at 0.5MPa
- Weight: 320g ±5%
- Dimensions: 105mm(L) × 34mm(W) × 34mm(H)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40
Compact rotary clamping cylinder combining linear motion with 90° rotation for precision positioning. Features dual piston design with anti-rotation guide for enhanced stability. The hardened stainless steel shaft resists side loads up to 15N·m. Requires filtered air (5-40μm) with ISO VG32 lubricant recommended.
- PCB board fixturing in electronics assembly
- Workpiece orientation in CNC machine loaders
- Tool changing mechanisms in robotic arms
- Precision alignment in optical component manufacturing
- Medical device assembly positioning
Installation note:
Mount using M4 screws (max torque 1.2N·m). Allow 0.5mm clearance
between clamp arm and workpiece. Lubricate every 500,000 cycles
using silicone-free grease.
| Property | Property Value |
|---|---|
| sku | QCKL12X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
