Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL12X20SMFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL12X20SMFB Rotary Clamping Cylinder Specifications
- Model: QCKL12X20SMFB
- Type: Double-acting rotary clamping cylinder with magnetic piston
- Bore size: Ø12mm
- Stroke: 20mm
- Operating pressure: 0.1–0.9 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Rotation angle: 90° ±5°
- Clamping force: 42N at 0.5MPa
- Buffer type: Adjustable rubber cushion
- Position detection: Built-in magnet for sensor mounting (PNP/NPN compatible)
- Mounting style: Front flange with 4xM3 threaded holes
- Body material: Aluminum alloy (anodized finish)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 280g ±5%
- Dimensions: 98mm(L) × 34mm(W) × 34mm(H)
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring integrated T-slot for tooling attachment. The dual-action design provides precise position control through compressed air in both extension/retraction directions. Enhanced wear resistance through chrome-plated piston rod and self-lubricating guide bushings.
- PCB fixture positioning in electronics assembly
- Workpiece orientation in CNC machine tool changers
- Automated jig clamping for robotic welding stations
- Precision component alignment in optical device manufacturing
- Rotary locking mechanisms in pharmaceutical packaging lines
Installation note:
Maintain 0.5mm minimum clearance between clamp arm and workpiece surface.
Use ISO VG32 hydraulic oil mist lubrication for optimal seal life.
Avoid side loads exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | QCKL12X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | LH (Left-Hand) |
