Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X10S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X10S Specifications
- Model: QCKL16X10S
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Clamping torque: 3.5 Nm (at 0.6 MPa)
- Rotation angle: 180° (±5° adjustable)
- Port size: M5x0.8 (1/8" NPT optional)
- Operation mode: Pneumatic rack-and-pinion mechanism
- Cushioning: Rubber buffer (both ends)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -20℃ to 80℃
- Protection rating: IP40
- Weight: 0.45kg ±2%
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H)
- Mounting hole spacing: 40mm (center-to-center)
- Rod end thread: M6x1.0
- Mounting hole diameter: 5mm
Compact rotary clamping cylinder with precision helical gear mechanism, featuring dual anti-rotation guides for enhanced stability. The hardened stainless steel shaft and aluminum alloy body ensure durability in high-cycle applications. Requires 5μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- Robotic end-effector tool changing systems
- CNC machine fixture positioning
- Automated assembly line part clamping
- Precision jig alignment in optical inspection equipment
- Medical device manufacturing tooling
Installation note:
Maintain 0.5-1mm clearance between clamping arm and workpiece surface.
For vertical mounting, install exhaust port downward to prevent debris ingress.
Maximum side load: 15N at rod extension.
Critical parameters:
- Do NOT exceed 120% of rated torque
- Maximum angular velocity: 90°/0.3sec
- Lubrication interval: 500,000 cycles (oil-free) / 1,000,000 cycles (lubricated)
| Property | Property Value |
|---|---|
| sku | QCKL16X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
