Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X10SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL16X10SFB Rotary Clamping Cylinder Specifications
- Model: QCKL16X10SFB
- Type: Double-acting rotary clamp cylinder
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90°±5° (automatic reset)
- Mounting type: Front flange with precision alignment grooves
- Port size: M5×0.8 (G1/8 equivalent)
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR + special polyurethane blend
- Temperature range: -20℃ to 80℃
- Weight: 0.45kg ±3%
- Dimensions: 78mm(L) × 42mm(W) × 42mm(H) (excluding rod)
- Rod thread: M6×1.0 internal thread
- Rotation torque: 0.35N·m @0.5MPa
- Repeat accuracy: ±0.2mm
- Protection rating: IP40 (dust-resistant)
Compact rotary clamp cylinder with integrated guide mechanism, featuring anti-vibration hardened steel shaft and wear-resistant bushing. The SFB variant includes a maintenance-free pre-lubricated system and shock-absorbing end caps. Requires 5μm filtered dry air (ISO 8573-1:2010 class 4) with 1-10 cSt viscosity oil mist lubrication (optional).
- PCB fixture positioning in SMT machines
- Automotive part clamping during robotic welding
- Medical device assembly tooling
- Semiconductor wafer handling systems
- Modular fixture quick-change stations
Installation note:
Maintain 0.5mm minimum clearance around rotating parts. For vertical mounting,
use counterbalance valve (optional accessory QVL-02). Lubricate guide rails
every 500,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | QCKL16X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
