Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X20S
$52.33
Regular price
$59.83
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
QCKL16X20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Designed for welding environments, the piston rod undergoes QPQ treatment, providing superior anti-slag properties compared to traditional hard chrome-plated surfaces;
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
Installation tips:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Use M5x12mm SHCS (socket head cap screws) for mounting with 4.4-5.4 N·m torque.
Lubricate guide rods with ISO VG32 hydraulic oil if operated beyond 60℃.
Avoid side-load forces exceeding 15N on the piston rod.
Maximum allowable lateral play: 0.3mm. For vertical mounting orientations,
install exhaust filters to prevent debris entry.
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X20S Technical Details
- Model: QCKL16X20S
- Type: Double-acting rotary clamp cylinder
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.1-0.8 MPa
- Clamping torque: 0.9 N·m @0.5 MPa
- Rotation angle: 90°±1° (standard)
- Port size: PT1/8 (G1/8 optional)
- Mounting style: Standard base plate with 4x M5 threaded holes
- Body material: Aluminum alloy (anodized)
- Piston rod: Hardened stainless steel
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.48 kg ±2%
- Dimensions:
- Length: 119mm (fully extended)
- Width: 45mm (body diameter)
- Height: 52mm (including mounting base)
- Repeat positioning accuracy: ±0.2mm
- Lubrication: Pre-lubricated (Grease-free operation)
Compact rotary clamp cylinder combining 90° rotation with vertical clamping force. Features precision-ground guide rods for smooth rotation and anti-rotation safety pins for position stability. Integrated cushioning mechanism reduces impact noise during rotation. Compatible with ISO 6432 mounting standards.
Typical Applications:
- CNC machine tool fixture switching
- Robotic arm end-effector tool changers
- Automated assembly line positioning jigs
- Semiconductor wafer handling systems
- Medical device component alignment
Installation tips:
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
Use M5x12mm SHCS (socket head cap screws) for mounting with 4.4-5.4 N·m torque.
Lubricate guide rods with ISO VG32 hydraulic oil if operated beyond 60℃.
Avoid side-load forces exceeding 15N on the piston rod.
Maximum allowable lateral play: 0.3mm. For vertical mounting orientations,
install exhaust filters to prevent debris entry.
| Property | Property Value |
|---|---|
| sku | QCKL16X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
