Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X20SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL16X20SFB Rotary Clamping Cylinder Specifications
- Model: QCKL16X20SFB
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.05–0.95 MPa
- Rotation angle: 90° ±5°
- Clamping force: 94N @0.5MPa
- Piston speed: 50–700mm/s
- Operating temperature: -10℃ to 70℃
- Port size: M5×0.8 (G1/8 adapter optional)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + PU composite
- Repeat accuracy: ±0.5mm
- Weight: 0.52kg
- Dimensions: 100mm(L) × 42mm(W) × 42mm(H)
- Accessories: Built-in magnetic sensor slot (PNP/NPN configurable)
- Protection rating: IP54
Compact rotary clamping cylinder with integrated rotation mechanism, combining vertical clamping and horizontal locking actions. Features wear-resistant composite seals and dual ball bearing rotation structure for smooth operation. Includes auto-lubrication design for maintenance-free operation up to 5,000km travel distance.
- CNC machine tool fixture positioning
- Automated welding jig systems
- PCB assembly line clamping
- Robotic arm end-effector tooling
- Medical device manufacturing stations
Installation note:
Ensure proper alignment of rotation axis before clamping. Use 0.3–1.0MPa dry air supply with 5μm filtration.
For vertical mounting, install locking pin (accessory code: QCLK-LP16) to prevent rotation drift.
| Property | Property Value |
|---|---|
| sku | QCKL16X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
