Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X20SM
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL16X20SM Rotary Clamping Cylinder Specifications
- Model: QCKL16X20SM
- Series: QCKL Compact Rotary Clamp
- Bore size: 16mm
- Stroke: 20mm
- Rotation angle: 90° ±5°
- Mounting style: Double bracket (standard)
- Material: Aluminum alloy body with hardened steel shaft
- Seal material: NBR (nitrile rubber)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Repeat positioning accuracy: ±0.5mm
- Buffer type: Adjustable cushioning
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Weight: 0.65 kg (1.43 lbs)
- Dimensions (L×W×H): 200mm × 50mm × 50mm
- Rod thread: M6x1.0 internal thread
- Rotation torque: 0.35 N·m @ 0.5 MPa
Compact rotary clamping cylinder combining linear motion with 90° rotation for precision workpiece positioning. Features dual-piston rack-and-pinion mechanism for smooth operation and anti-backlash design. Includes magnetic sensor slots (Φ4.5mm) for position feedback. Requires filtered lubricated air (ISO 8573-1 class 3.4.3).
- Robotic arm end-effector tool changing
- CNC machine fixture positioning
- Automated assembly line clamping
- PCB handling equipment
- Precision mold clamping systems
Installation note:
Maintain 0.5mm minimum clearance between clamp arm and workpiece surface.
Use Loctite 243 on mounting screws (max torque 3.5 N·m).
Lubricate every 500,000 cycles with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | QCKL16X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
