Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X30S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X30S Technical Details
- Model: QCKL16X30S
- Type: Rotary clamping cylinder with mechanical lock
- Bore size: 16mm
- Stroke: 30mm
- Rotation angle: 90°±5°
- Operating pressure: 0.1-0.8 MPa
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston speed: 50-700mm/s
- Cushioning: Adjustable rubber bumper
- Mounting style: Standard base mounting with 4xM4 threaded holes
- Body material: Aluminum alloy (anodized surface)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR + PU composite
- Temperature range: -20℃ to 80℃
- Weight: 520g ±2%
- Dimensions: 98mm(L) × 42mm(W) × 42mm(H)
- Torque output: 1.2N·m @0.5MPa
- Repeat positioning accuracy: ±0.5mm
- Protection rating: IP54 (standard) / IP67 (optional)
High-precision rotary clamping cylinder featuring dual-action mechanical locking mechanism with self-lubricating bearings. The 3-stage sealing system ensures leak-free operation even in high-cycle applications (up to 1.5 million cycles). Integrated T-slot design allows direct fixture mounting without additional brackets.
- CNC machine tool workpiece fixturing
- Robotic welding station position locking
- PCB assembly line component retention
- Automated inspection equipment positioning
- Medical device manufacturing jigs
Installation note:
Ensure proper alignment of rotary axis before operation. Lubricate guide shafts with ISO VG32 hydraulic oil
during maintenance. Maximum side load capacity: 30N perpendicular to rod axis.
Critical parameters:
Maintain air filtration at 25μm or finer. Avoid rapid pressure changes >0.3MPa/sec.
For vertical mounting, install a mechanical safety stop as secondary protection.
| Property | Property Value |
|---|---|
| sku | QCKL16X30S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
