Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL16X30SFB
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Rotary Clamping Cylinder QCKL16X30SFB Technical Details
- Model: QCKL16X30SFB
- Type: Rotary clamp cylinder with auto-rotation mechanism
- Bore size: 16mm
- Stroke: 30mm
- Operating pressure: 0.1–0.7 MPa
- Clamping torque: 0.8 N·m (at 0.5 MPa)
- Rotation angle: 90° ±5°
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU hybrid seals
- Mounting type: Standard base mounting (ISO 15552 compatible)
- Port size: M5x0.8 (dual ports for bi-directional control)
- Temperature range: -10℃ to 80℃
- Weight: 480g ±2%
- Dimensions: 132mm(L) × 42mm(W) × 42mm(H)
- Repeat accuracy: ±0.2mm
- Response time: ≤0.3s (at 0.5 MPa)
- Protection class: IP54 (standard)
Precision rotary clamping cylinder combining linear motion with 90° rotation for secure workpiece fixation. Features anti-vibration design with built-in cushioning and wear-resistant guides. The SFB variant includes enhanced dust wipers and optional magnetic sensor slots (sensors sold separately). Requires filtered air with 5-40μm filtration.
- CNC machine tool fixture positioning
- Automated welding jig systems
- PCB assembly line clamping units
- Robotic arm end-effector tooling
- Optical lens polishing station locking
Operation tip:
For optimal performance, maintain air supply pressure above 0.3 MPa during rotation phase.
Lubricate pivot points every 50,000 cycles using ISO VG32 hydraulic oil.
Critical note:
Avoid side-load impacts during clamping operations. Maximum allowable
lateral force: 15N. Always engage mechanical lock before maintenance.
| Property | Property Value |
|---|---|
| sku | QCKL16X30SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | LH (Left-Hand) |
