Airtac AirTAC QCKL Rotary Clamp Cylinder QCKL25X10-S
2. Equipped with a stainless steel scraper ring on the front cover for enhanced durability, effectively resisting welding spatter and dust ingress—more reliable than standard dust boots;
3. Identical installation dimensions and mounting configurations to the ACQ series, allowing compatibility with ACQ mounting accessories.
Category: Rotary Clamping Cylinders , Brand: AirTAC , Series: QCKL （Key technical terms: QPQ treatment, anti-slag, hard chrome-plated, scraper ring, dust ingress, mounting configurations）
AirTAC QCKL Series Rotary Clamping Cylinder QCKL25X10-S Technical Details
- Model: QCKL25X10-S
- Type: Double-acting rotary clamping cylinder
- Bore size: Ø25mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90° (±1° precision)
- Clamping torque: 3.5 N·m (dynamic), 12 N·m (static)
- Port size: M5×0.8 (G1/8 optional)
- Cushioning: Rubber pad buffer
- Seal material: NBR + PU composite
- Temperature range: -10℃ to 80℃
- Weight: 1.8kg (with standard accessories)
- Dimensions: 145mm(L) × 75mm(W) × 75mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Mounting: M6 threaded holes (4x)
Precision-engineered rotary clamping cylinder combining linear motion with 90° rotation for secure workpiece fixation. Features anti-vibration design with hardened guide rods and wear-resistant bushings. The dual-piston structure ensures synchronous rotation and clamping force, with TÜV-certified safety locking mechanism.
- CNC machine tool fixture systems
- Automotive welding jig positioning
- Robotic arm end-effector tooling
- Electronics assembly precision clamping
- Medical device manufacturing stations
Installation note:
Requires 5-7μm filtered lubricated air (ISO 8573-1 class 3).
For optimal performance, maintain 0.3-0.6 MPa working pressure and
lubricate guide shafts every 500,000 cycles using ISO VG32 hydraulic oil.
Critical parameters:
Maximum lateral load 150N, axial load 300N.
Avoid exceeding 2.5Hz operation frequency to prevent heat buildup.
| Property | Property Value |
|---|---|
| sku | QCKL25X10-S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Direction Code | LH (Left-Hand) |
