Airtac ATE Single Acting Guided Compact Cylinder ATE100X10B
$114.21
Regular price
$121.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation note:
Ensure piston rod alignment within 0.5° angular tolerance. Use M6 mounting screws with 8.8-grade
or higher fasteners. Lubricate with ISO VG32 turbine oil if operating below 0.3 MPa. Avoid
side-load exceeding 15% of maximum thrust capacity.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X10B Single-Acting Compact Cylinder Specifications
- Model: ATE100X10B
- Type: Single-acting spring return (push type)
- Bore size: 100mm
- Stroke: 10mm (customizable up to 300mm)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: G1/8 (NPT1/8 optional)
- Mounting style: Basic rear clevis
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (nitrile) with grease retention design
- Protection rating: IP40 (IP67 with optional wiper)
- Piston rod material: Hard chrome-plated carbon steel
- Tube finish: Anodized aluminum alloy
- Weight: 2.8kg (standard configuration)
- Dimensions: 210mm(L) × 100mm(W) × 100mm(H)
A space-saving pneumatic actuator featuring high rigidity guide rods and anti-rotation mechanism. The optimized seal structure reduces stick-slip effect during low-speed operation. Ideal for vertical mounting configurations requiring precise linear motion with minimal footprint. Compatible with AirTAC's modular accessory system (MA series).
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Clamping fixtures for CNC machine tooling
- Vertical lifting mechanisms in packaging lines
- Material sorting gates in logistics automation
- Pressurization systems for food processing equipment
Installation note:
Ensure piston rod alignment within 0.5° angular tolerance. Use M6 mounting screws with 8.8-grade
or higher fasteners. Lubricate with ISO VG32 turbine oil if operating below 0.3 MPa. Avoid
side-load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | ATE100X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
