Airtac ATE Single Acting Guided Compact Cylinder ATE100X5B
$112.81
Regular price
$120.31
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X5B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation protocol:
Maintain 0.5–1mm alignment tolerance during mounting. Use copper-based anti-seize compound
on rod threads. For vertical installations, add 20% safety factor to load calculations.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X5B Single-Acting Compact Cylinder Specifications
- Model: ATE100X5B (Basic Series)
- Type: Single-acting spring return (push type)
- Bore size: Ø100mm ±0.5mm tolerance
- Stroke: 5mm (adjustable cushioning)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max thrust: 628N @ 0.6MPa (calculated)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800mm/s (lubricated)
- Mounting types: Front flange (MF1), rear flange (MF2), or foot mounting
- Cushion type: Adjustable pneumatic cushion
- Port size: Rc1/4 (NPT1/4 optional)
- Seal material: NBR + polyurethane hybrid seals
- Protection rating: IP65 (standard wiper design)
- Weight: 1.8kg ±3% (without accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (full extension)
- Rod thread: M16×1.5 external thread (stainless steel)
High-force compact cylinder optimized for confined spaces, featuring a reinforced anodized aluminum body with corrosion-resistant coating. The dual-cushion design reduces end-impact noise to ≤75dB. Requires ISO VG32 or equivalent turbine oil lubrication. Compatible with ATEX Zone 2 environments when using anti-static seals (optional).
Typical Applications:
- Press machine ejection systems (5–10 ton presses)
- Conveyor gate actuation in logistics sorting
- Metal stamping die cushion mechanisms
- Plastic injection molding clamp assists
- Solar panel frame assembly jigs
Installation protocol:
Maintain 0.5–1mm alignment tolerance during mounting. Use copper-based anti-seize compound
on rod threads. For vertical installations, add 20% safety factor to load calculations.
Lubrication cycle:
Every 500km stroke travel or 6 months (whichever comes first).
Replace wiper seal after 1 million cycles in high particulate environments.
| Property | Property Value |
|---|---|
| sku | ATE100X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <5mm> |
