Airtac B03-4M Explosion-proof Solenoid Valve B03-4M21008B
AirTAC B03-4M Explosion-Proof Solenoid Valve B03-4M21008B Technical Details
- Full model designation: B03-4M21008B
- Valve type: 3/2-way normally closed (direct-acting explosion-proof)
- Explosion-proof certification: ATEX/IECEx Ex d IIC T6 Gb
- Port connection: G1/8" BSPP (NPT optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC/DC110-220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Power consumption: DC: 2.5W max | AC: 3.5VA max
- Seal material: Fluorocarbon rubber (FKM) standard (EPDM optional)
- Ambient temperature: -20℃ to +60℃ (medium temp: 0-60℃)
- Response time: ≤15ms (energize) / ≤20ms (de-energize)
- Protection rating: IP67 (dust/water resistant)
- Housing material: Aluminum alloy with anti-corrosion coating
- Weight: 1.2kg ±5% (including coil assembly)
- Dimensions: 120mm(L) × 75mm(W) × 65mm(H)
Heavy-duty explosion-proof solenoid valve with intrinsically safe circuit design, featuring copper-free aluminum alloy construction to prevent mechanical sparks. The valve incorporates dual-seal technology with military-grade epoxy encapsulation, suitable for Zone 1/21 hazardous areas. Requires 5μm filtered compressed air with max 0.1% oil content.
- Petrochemical processing equipment
- Coal mine ventilation control systems
- Grain silo pneumatic conveying
- Paint spray booth automation
- Offshore platform machinery
- Flammable gas detection systems
Critical installation requirements:
Must be grounded via M8 terminal with ≤4Ω resistance. Maintain minimum 50mm clearance
from adjacent non-certified equipment. Use only with certified explosion-proof conduits.
| Property | Property Value |
|---|---|
| sku | B03-4M21008B |
