Airtac B03-4M Explosion-proof Solenoid Valve B03-4M22008A
AirTAC B03-4M22008A Explosion-Proof Solenoid Valve Specifications
- Full model: B03-4M22008A
- Series: B03-4M Ex-proof series
- Valve type: 3-position 5-way (double solenoid)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa (7-116 PSI)
- Max flow rate: 750 L/min (Cv=1.3)
- Voltage options: DC24V±10% / AC220V±10% 50/60Hz
- Power consumption: 2.8W (AC) / 3.6W (DC)
- Explosion-proof certification: Ex d IIB T6 Gb / Ex tD A21 IP66 T80°C
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Body material: Aluminum alloy with anti-static coating
- Response time: ≤15ms (at 0.5MPa)
- Weight: 720g ±5% (with accessories)
- Dimensions: 100mm(L) × 52mm(W) × 90mm(H)
- Port thread depth: 12mm (NPT) / 10mm (G)
- Manual override: Built-in emergency switch
Heavy-duty explosion-proof solenoid valve with dual certifications for gas (ATEX) and dust environments. Features copper-free aluminum construction to prevent spark generation, redundant sealing layers, and thermal overload protection. Requires 5μm filtration and automatic drain installation in hazardous areas.
- Petrochemical pipeline control systems
- Coal mine ventilation equipment
- Paint spray booth automation
- Grain silo pneumatic conveying
- Oil & gas wellhead control devices
- Flammable chemical storage facilities
Installation requirements:
Must be grounded via dedicated M6 terminal. Maintain 50cm minimum clearance from other ignition sources.
Use only in ambient temperatures below 80℃. Conduct monthly manual override tests.
- AirTAC VF-3000 series filters
- APEB-02 explosion-proof junction boxes
- SL-04M surge suppressor modules
| Property | Property Value |
|---|---|
| sku | B03-4M22008A |
