Airtac B03-4M Explosion-proof Solenoid Valve B03-4M32008B
AirTAC B03-4M32008B Explosion-Proof Solenoid Valve Specifications
- Model: B03-4M32008B (B03-4M series)
- Type: 3/2-way normally closed direct-acting with explosion-proof design
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa (21–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 L/min (Cv=1.2)
- Weight: 0.85 kg (1.87 lbs)
- Dimensions: 80mm(L) × 54mm(W) × 98mm(H)
- Body material: Aluminum alloy with anti-corrosion treatment
- Seal material: High-temperature resistant FKM (Viton®)
- Temperature range: -20℃ to 150℃ (medium temp), -5℃ to 80℃ (ambient)
- Power consumption: ≤2.5W (DC), ≤5.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Explosion-proof certification: Ex d IIC T6 Gb (ATEX/IECEx compliant)
- Response time: ≤15ms (open/close cycle)
- Port thread depth: 12mm (minimum engagement)
Heavy-duty explosion-proof solenoid valve featuring brass core tube and military-grade coil insulation. Designed for hazardous environments with Class I/II gas/dust atmospheres. Incorporates double-sealed conduit entry points and spark containment chamber. Requires 5μm filtration for optimal performance.
- Petrochemical processing equipment
- Coal mine ventilation systems
- Grain silo pneumatic controls
- Paint spray booth automation
- Oil refinery emergency shutoff systems
- Gas station vapor recovery units
Installation requirements:
Must be grounded via M8 terminal. Maintain 50mm clearance from combustible surfaces.
Use copper-free anti-seize compound on threads. Perform monthly manual override testing.
| Property | Property Value |
|---|---|
| sku | B03-4M32008B |
