Airtac B03-4M Explosion-proof Solenoid Valve B03-4M32010B
AirTAC B03-4M32010B Explosion-Proof Solenoid Valve Specifications
- Model: B03-4M32010B
- Type: 3/2-way normally closed (direct-acting with explosion-proof housing)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±5% (with coil)
- Dimensions: 85mm(L) × 48mm(W) × 68mm(H)
- Seal material: Fluororubber (FKM) for chemical resistance
- Temperature range: -20℃ to +80℃ (ambient/medium)
- Power consumption: 2.2W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (dust/waterproof)
- Explosion-proof certification: Ex d IIB T4 Gb (ATEX/IECEx compliant)
- Valve body material: Nickel-plated brass
- Response time: ≤15ms (at 0.5MPa)
- Maximum flow rate: 750L/min (ANR)
- Port thread depth: 12mm
Heavy-duty explosion-proof solenoid valve with reinforced brass construction and military-grade sealing. Features dual-chamber blast-proof design that contains internal sparks, certified for Zone 1 hazardous areas. Requires 5μm filtration (lubricated or non-lubricated air). Includes manual override and surge protection circuitry.
- Petrochemical plant gas control systems
- Coal mine ventilation equipment
- Grain silo pneumatic conveying
- Paint spray booth safety shut-off
- Fuel storage tank venting systems
- Offshore drilling platform controls
Installation critical:
Must be grounded with 4mm² minimum wire. Maintain 30cm clearance from other ignition sources.
Use only in groups IIA/IIB gases (excluding hydrogen). Torque mounting bolts to 12N·m ±10%.
| Property | Property Value |
|---|---|
| sku | B03-4M32010B |
